DXC-D30 (UC)
DXC-D30P (CE)
2-7
VF (20P, FEMALE)
LENS (12P, FEMALE)
(EXTERNAL VIEW)
1
6
11
16
5
10
15
20
(EXTERNAL VIEW)
10
5
46
73
1112
82
19
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
12
Signal
RET SW-IN
VTR START/STOP IN
POWER +12 V DC GND
COMPULSORY AUTO IRIS
CONT OUT
IRIS CONT OUT
POWER +12 V DC OUT
IRIS POSI IN
REMOTE/LOCAL OUT
EXTND ON/OFF IN
ZOOM POSI IN
(SPARE)
(SPARE)
Specification
ON : 0 ± 0.5 Vdc
TRIG : 0 ± 0.5 V
GND for +12 Vdc
AUTO : 4.5 ± 0.5 V
MANU : 0 + 0.5 V or OPEN
F16 : 3.4 Vdc
F2.8 : 6.2 Vdc
10.6 V to 17.0 Vdc
F16 : 3.4 ± 0.1 Vdc
F2.8 : 6.2 ± 0.1 Vdc
REMOTE : 5 V
LOCAL: 0 V
2 1
3
MIC (3P, FEMALE)
(EXTERNAL VIEW)
Signal
MIC (G) IN
MIC (X) IN
MIC (Y) IN
Specification
GND for MIC
Pin
No.
1
2
3
–60 dB
BALANCED
(0 dB = 0.775 V)
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Signal
PEAKING CONT IN
SWD EXT DC OUT
REC TALLY IND OUT
BATT IND OUT
ZEBRA SW IN
VF VIDEO (X) OUT
SWD EXT DC OUT
(SPARE)
(SPARE)
SDA (VF) OUT
VF VIDEO (G) OUT
EXT DC GND
(SPARE)
(SPARE)
SCL (VF) OUT
R-Y (VF) OUT
EXT DC GND
B-Y (VF) OUT
SYNC (VF) OUT
LD (VF) OUT
Specification
Zi > 5 kΩ
10.5 V to 17.0 Vdc, 2 A
Zo < 500 Ω
Zo < 1.1 kΩ
ON : 0 ± 0.5 V
V = 1.0 Vp-p
10.5 V to 17.0 Vdc, 2 A
Zo < 500 Ω, 5 Vp-p
GND for VF VIDEO
GND for EXIT DC
Zo < 500 Ω, 5 Vp-p
V = 830 mV
GND for EXIT DC
V = 830 mV
V = 5 Vp-p
Zo < 500 Ω, 5 Vp-p
