24
Board
PWB
(A side)
BLM (KM, KMW, KML, KMLW, KL, KLW) Details
Checking
Audio Error
pin not short
to GND
3b.1 : 3x Blinking – Audio Error
BLM Board (Checking Point)
CN9601
Main IC
(IC5000)
Details
Audio Error pin
