Sony HCD-BC150 - Base Unit (DVBU100); Optical Pick-Up (KHM-310 AAB;C2 NP)

14
HCD-BC150/BC250
1 two floating screw
s
(+PTPWH2.6)
2 floating screw
(+PTPWH2.6)
3 base unit (DVBU100)
1 two screws
(+BTP 2.6
× 8 )
2 two screws
(+BTP 2.6
× 8 )
6 holder (310) assy
4 insulator screw
7 insulator screw
qd optical pick-up
(KHM-310AAB/C2NP)
5
0
insulator
qa insulator
8 insulator scre
w
qs insulator
3 insulator screw
9 insulator
2-14. BASE UNIT (DVBU100)
2-15. OPTICAL PICK-UP (KHM-310AAB/C2NP)
