Sony HCD-BC150 - 2-12. TRAY; 2-13. MOTOR BOARD, M761 (LD;ST MOTOR), M762 (BU U;D MOTOR)

13
HCD-BC150/BC250
2-12. TRAY
1 two screws
(+BTP 2.6
× 8)
2 two screws
(+BTP 2.6
× 8)
3 bracket
4
5
tray
1 screw
(+BTP 2.6 × 8)
2 bracket
3 screw
(+BTP 2.6 × 8)
4 MOTOR board
5 Remove soldering from the two points.
6 M761 (LD/ST MOTOR)
7 Remove soldering from the two points.
8 M762 (BU U/D MOTOR)
2-13. MOTOR BOARD, M761 (LD/ST MOTOR), M762 (BU U/D MOTOR)
