HCD-BC150/BC250
SECTION 4
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. ., uPA. . : µPA. .,
uPB. . : µPB. ., uPC. . : µPC. .,
uPD. . : µPD. .
•Abbreviation
AUS:Australian model
CND : Canadian model
E41 : 230V AC Area in E model
EA : Saudi Arabia model
KR : Korea model
MX : Mexican model
TW : Taiwan modell
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
AMP
A-1052-860-A AMP BOARD, COMPLETE (150: MX)
A-1053-123-A AMP BOARD, COMPLETE (TW, EA, AUS)
A-1054-633-A AMP BOARD, COMPLETE (E41)
A-1062-134-A AMP BOARD, COMPLETE (250: US, CND)
A-1067-906-A AMP BOARD, COMPLETE (250: MX)
A-4752-734-A AMP BOARD, COMPLETE (150: US, CND, KR)
*********************
< CAPACITOR >
C101 1-164-346-11 CERAMIC CHIP 1uF 16V
C102 1-164-346-11 CERAMIC CHIP 1uF 16V
C103 1-164-346-11 CERAMIC CHIP 1uF 16V
C104 1-164-346-11 CERAMIC CHIP 1uF 16V
C105 1-164-346-11 CERAMIC CHIP 1uF 16V
C106 1-164-346-11 CERAMIC CHIP 1uF 16V
C111 1-164-346-11 CERAMIC CHIP 1uF 16V
C112 1-164-346-11 CERAMIC CHIP 1uF 16V
C113 1-164-346-11 CERAMIC CHIP 1uF 16V
C114 1-164-346-11 CERAMIC CHIP 1uF 16V
C115 1-164-346-11 CERAMIC CHIP 1uF 16V
C116 1-164-346-11 CERAMIC CHIP 1uF 16V
C131 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C132 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C134 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C136 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C138 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C141 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C142 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C143 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C144 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C145 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C146 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C148 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C149 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C151 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C152 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C153 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C154 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C155 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C156 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C158 1-126-947-11 ELECT 47uF 20% 35V
C160 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C161 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C162 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C163 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C164 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C165 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C166 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C168 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C171 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C172 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C173 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C174 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C175 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C176 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C178 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C181 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C182 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C183 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C184 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C185 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C186 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C188 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C189 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C190 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C191 1-107-898-11 ELECT 2200uF 20% 35V
C192 1-107-898-11 ELECT 2200uF 20% 35V
C193 1-107-898-11 ELECT 2200uF 20% 35V
C194 1-107-898-11 ELECT 2200uF 20% 35V
C195 1-107-898-11 ELECT 2200uF 20% 35V
(EXCEPT 250: MX)
C196 1-110-617-51 ELECT 2200uF 20% 50V
(EXCEPT 250: MX)
C198 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C199 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C200 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C202 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C203 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C204 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C205 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C206 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
When indicating parts by reference number,
please include the board name.
