Sony HCD-BC150 - SECTION 2 DISASSEMBLY; 2-1. DISASSEMBLY FLOW

6
HCD-BC150/BC250
SECTION 2
DISASSEMBLY
2-1. DISASSEMBLY FLOW
•This set can be disassembled in the order shown below.
2-4.SWITCHING REGULATOR
(Page 8)
2-5.AMP BOARD
(Page 9)
2-8.MAIN BOARD
(Page 10)
2-9.LF BOARD
(Page 11)
2-10.MD REAR COVER
(Page 11)
2-11.DVD MECHANISM DECK
(CDM81A-DVBU27)
(Page 12)
2-7.SPK BOARD, IO BOARD,
DC FAN
(Page 10)
2-6.DMB07 BOARD
(Page 9)
2-3.PANEL BOARD,
FL BOARD, H/P BOARD,
POWER SW BOARD
(Page 8)
2-2.CASE,
FRONT PANEL ASSY SECTION
(Page 7)
SET
2-12.TRAY
(Page 13)
2-13.MOTOR BOARD,
M761 (LD/ST MOTOR),
M762 (BU U/D MOTOR)
(Page 13)
2-14.BASE UNIT (DVBU27)
(Page 14)
2-15.RF BOARD
(Page 14)
2-16.OPTICAL PICK-UP
(DBU-1)
(Page 15)
