Sony HCD-BC150 - Page 38

38
HCD-BC150/BC250
Ver 1.3
– DMB07 Board –
qg IC207 <zz. (VDAC_4)
(EXCEPT AEP,UK)
H
980 mVp-p
200 mV/DIV, 20
µ s/DIV
– MAIN Board –
qh IC509 qf (X1)
200 ns
2.4 Vp-p
1 V/DIV, 100 ns/DIV
– IO Board –
qj IC201 wd (CVBS OUT)
H
3 Vp-p
1 V/DIV, 20
µ s/DIV
qk IC201 wh (COUT)
H
2.4 Vp-p
1 V/DIV, 20
µ s/DIV
ql IC201 wa (YOUT)
H
2.1 Vp-p
1 V/DIV, 20 µ s/DIV
– AMP Board –
w; IC108 rk (XFSOIN)
20.3 ns
5.9 Vp-p
1 V/DIV, 10 ns/DIV
