Sony HCD-BX2 - Page 47

47
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< LED >
LED901 8-719-812-41 LED SEL2110R (TIMER)
LED902 8-719-812-41 LED SEL2110R (STANDBY)
LED903 8-719-317-11 LED SEL1710Y (CD)
LED904 8-719-317-11 LED SEL1710Y (TAPE A/B)
LED905 8-719-317-11 LED SEL1710Y (TUNER/BAND)
LED906 8-719-317-11 LED SEL1710Y (MD)
LED907 8-719-317-11 LED SEL1710Y (GROOVE)
LED908 8-719-317-11 LED SEL1710Y (REC)
LED909 8-719-921-01 LED SEL1110R (REC PAUSE)
LED910 8-719-312-70 LED SEL1410G (G)
LED911 8-719-312-70 LED SEL1410G (g)
< TRANSISTOR >
Q601 8-729-194-57 TRANSISTOR 2SC945TP-P
Q602 8-729-194-57 TRANSISTOR 2SC945TP-P
Q603 8-729-194-57 TRANSISTOR 2SC945TP-P
Q604 8-729-119-76 TRANSISTOR 2SA733-P
Q901 8-729-194-57 TRANSISTOR 2SC945TP-P
Q902 8-729-194-57 TRANSISTOR 2SC945TP-P
< RESISTOR >
R601 1-247-871-11 CARBON 47K 5% 1/4W
R602 1-249-417-11 CARBON 1K 5% 1/4W
R603 1-247-871-11 CARBON 47K 5% 1/4W
R604 1-249-417-11 CARBON 1K 5% 1/4W
R605 1-247-871-11 CARBON 47K 5% 1/4W
R606 1-249-417-11 CARBON 1K 5% 1/4W
R607 1-249-431-11 CARBON 15K 5% 1/4W
R608 1-247-871-11 CARBON 47K 5% 1/4W
R612 1-247-855-11 CARBON 10K 5% 1/4W
R613 1-247-855-11 CARBON 10K 5% 1/4W
R614 1-247-855-11 CARBON 10K 5% 1/4W
R615 1-247-855-11 CARBON 10K 5% 1/4W
R616 1-247-855-11 CARBON 10K 5% 1/4W
R617 1-247-855-11 CARBON 10K 5% 1/4W
R618 1-247-855-11 CARBON 10K 5% 1/4W
R619 1-247-855-11 CARBON 10K 5% 1/4W
R620 1-247-855-11 CARBON 10K 5% 1/4W
R621 1-247-855-11 CARBON 10K 5% 1/4W
R622 1-247-855-11 CARBON 10K 5% 1/4W
R623 1-247-855-11 CARBON 10K 5% 1/4W
R624 1-247-855-11 CARBON 10K 5% 1/4W
R625 1-247-855-11 CARBON 10K 5% 1/4W
R626 1-247-855-11 CARBON 10K 5% 1/4W
R657 1-247-835-11 CARBON 1.5K 5% 1/4W
R658 1-247-887-00 CARBON 220K 5% 1/4W
R659 1-247-871-11 CARBON 47K 5% 1/4W
R660 1-247-895-00 CARBON 470K 5% 1/4W
R661 1-247-871-11 CARBON 47K 5% 1/4W
R662 1-247-895-00 CARBON 470K 5% 1/4W
R664 1-247-871-11 CARBON 47K 5% 1/4W
R665 1-247-895-00 CARBON 470K 5% 1/4W
R666 1-247-835-11 CARBON 1.5K 5% 1/4W
R668 1-247-871-11 CARBON 47K 5% 1/4W
R669 1-247-895-00 CARBON 470K 5% 1/4W
R671 1-247-867-11 CARBON 33K 5% 1/4W
R672 1-247-895-00 CARBON 470K 5% 1/4W
R673 1-247-835-11 CARBON 1.5K 5% 1/4W
R674 1-247-835-11 CARBON 1.5K 5% 1/4W
R676 1-247-835-11 CARBON 1.5K 5% 1/4W
R680 1-247-871-11 CARBON 47K 5% 1/4W
R903 1-247-847-11 CARBON 4.7K 5% 1/4W
R904 1-247-847-11 CARBON 4.7K 5% 1/4W
R906 1-249-410-11 CARBON 270 5% 1/4W
R907 1-249-410-11 CARBON 270 5% 1/4W
R908 1-249-410-11 CARBON 270 5% 1/4W
R909 1-249-410-11 CARBON 270 5% 1/4W
R910 1-249-410-11 CARBON 270 5% 1/4W
R911 1-249-417-11 CARBON 1K 5% 1/4W
R912 1-249-413-11 CARBON 470 5% 1/4W
R915 1-247-855-11 CARBON 10K 5% 1/4W
R916 1-247-855-11 CARBON 10K 5% 1/4W
R917 1-249-410-11 CARBON 270 5% 1/4W
R921 1-249-410-11 CARBON 270 5% 1/4W
R922 1-247-827-11 CARBON 680 5% 1/4W
R923 1-249-416-11 CARBON 820 5% 1/4W
R924 1-249-418-11 CARBON 1.2K 5% 1/4W
R925 1-247-835-11 CARBON 1.5K 5% 1/4W
R926 1-247-839-11 CARBON 2.2K 5% 1/4W
R927 1-247-843-11 CARBON 3.3K 5% 1/4W
R928 1-247-847-11 CARBON 4.7K 5% 1/4W
R929 1-249-428-11 CARBON 8.2K 5% 1/4W
R930 1-249-431-11 CARBON 15K 5% 1/4W
R931 1-249-434-11 CARBON 27K 5% 1/4W
R932 1-247-827-11 CARBON 680 5% 1/4W
R933 1-249-416-11 CARBON 820 5% 1/4W
R934 1-249-418-11 CARBON 1.2K 5% 1/4W
R935 1-247-835-11 CARBON 1.5K 5% 1/4W
R936 1-247-839-11 CARBON 2.2K 5% 1/4W
R937 1-247-843-11 CARBON 3.3K 5% 1/4W
R938 1-247-847-11 CARBON 4.7K 5% 1/4W
R939 1-249-428-11 CARBON 8.2K 5% 1/4W
R940 1-249-431-11 CARBON 15K 5% 1/4W
R942 1-247-827-11 CARBON 680 5% 1/4W
R943 1-249-416-11 CARBON 820 5% 1/4W
R944 1-249-428-11 CARBON 8.2K 5% 1/4W
R948 1-247-847-11 CARBON 4.7K 5% 1/4W
R949 1-249-428-11 CARBON 8.2K 5% 1/4W
R950 1-249-434-11 CARBON 27K 5% 1/4W
R955 1-249-408-11 CARBON 180 5% 1/4W
R956 1-249-408-11 CARBON 180 5% 1/4W
R618A 1-247-879-11 CARBON 100K 5% 1/4W
< SWITCH >
S902 1-572-647-11 SWITCH, KEY BOARD (> +)
S903 1-572-647-11 SWITCH, KEY BOARD (J)
S904 1-572-647-11 SWITCH, KEY BOARD (TUNER MEMORY, EDIT)
S905 1-572-647-11 SWITCH, KEY BOARD
(REPEAT, STEREO/MONO)
S906 1-572-647-11 SWITCH, KEY BOARD
(PLAY MODE, DIRECTION)
S907 1-572-647-11 SWITCH, KEY BOARD (X)
S908 1-572-647-11 SWITCH, KEY BOARD (g G)
FRONT
