Sony HCD-BX2 - Page 48

48
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S909 1-572-647-11 SWITCH, KEY BOARD (x)
S910 1-572-647-11 SWITCH, KEY BOARD (– .)
S911 1-572-647-11 SWITCH, KEY BOARD (GROOVE)
S912 1-572-647-11 SWITCH, KEY BOARD (FILE SELECT)
S913 1-572-647-11 SWITCH, KEY BOARD (ENTER)
S914 1-572-647-11 SWITCH, KEY BOARD (SPECTRUM)
S915 1-572-647-11 SWITCH, KEY BOARD (DISPLAY)
S917 1-572-647-11 SWITCH, KEY BOARD (?/1)
S918 1-572-647-11 SWITCH, KEY BOARD (Z OPEN/CLOSE)
S919 1-572-647-11 SWITCH, KEY BOARD (DISC 3)
S920 1-572-647-11 SWITCH, KEY BOARD (DISC 2)
S921 1-572-647-11 SWITCH, KEY BOARD (DISC 1)
S922 1-572-647-11 SWITCH, KEY BOARD
(DISC SKIP EX-CHANGE)
S923 1-572-647-11 SWITCH, KEY BOARD (TUNER/BAND)
S924 1-572-647-11 SWITCH, KEY BOARD (CD)
S925 1-572-647-11 SWITCH, KEY BOARD (TAPE A/B)
S926 1-572-647-11 SWITCH, KEY BOARD (MD)
S927 1-572-647-11 SWITCH, KEY BOARD (j)
S931 1-572-647-11 SWITCH, KEY BOARD (REC)
S932 1-572-647-11 SWITCH, KEY BOARD (REC PAUSE)
S933 1-572-647-11 SWITCH, KEY BOARD (CD SYNC)
< VARIABLE RESISTOR >
VR602 4-229-524-01 ROTARY, ENCODER (VOLUME)
< VIBRATOR >
X601 1-567-925-11 VIBRATOR, CRYSTAL (10MHz)
**************************************************************
A-4473-610-A H/P BOARD, COMPLETE
********************
< CAPACITOR >
C760 1-161-494-00 CERAMIC 0.022uF 25V
C761 1-161-494-00 CERAMIC 0.022uF 25V
< JACK >
JK701 1-569-612-11 JACK, MINIATURE (PHONES)
**************************************************************
A-4473-603-A MAIN BOARD, COMPLETE (US)
*************************
* 1-533-213-31 HOLDER, FUSE
< CAPACITOR >
C101 1-162-199-31 CERAMIC 10PF 5% 50V
C113 1-161-494-00 CERAMIC 0.022uF 25V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-161-494-00 CERAMIC 0.022uF 25V
C117 1-162-199-31 CERAMIC 10PF 5% 50V
C118 1-126-933-11 ELECT 100uF 20% 16V
C120 1-164-206-41 CERAMIC 0.047uF 99% 50V
C121 1-162-211-31 CERAMIC 33PF 5% 50V
C122 1-126-960-11 ELECT 1uF 20% 50V
C123 1-126-959-11 ELECT 0.47uF 20% 50V
C124 1-162-206-31 CERAMIC 20PF 5% 50V
C125 1-126-960-11 ELECT 1uF 20% 50V
C126 1-164-206-41 CERAMIC 0.047uF 99% 50V
C127 1-126-964-11 ELECT 10uF 20% 50V
C128 1-161-494-00 CERAMIC 0.022uF 25V
C129 1-126-964-11 ELECT 10uF 20% 50V
C130 1-137-352-11 MYLAR 0.033uF 5% 100V
C131 1-137-352-11 MYLAR 0.033uF 5% 100V
C135 1-162-293-31 CERAMIC 820PF 10% 50V
C137 1-126-963-11 ELECT 4.7uF 20% 50V
C138 1-164-159-11 CERAMIC 0.1uF 50V
C139 1-161-494-00 CERAMIC 0.022uF 25V
C140 1-126-933-11 ELECT 100uF 20% 16V
C141 1-161-494-00 CERAMIC 0.022uF 25V
C142 1-126-933-11 ELECT 100uF 20% 16V
C143 1-137-378-11 MYLAR 0.22uF 5% 50V
C144 1-137-150-11 MYLAR 0.01uF 5% 100V
C146 1-162-294-31 CERAMIC 0.001uF 10% 50V
C148 1-161-494-00 CERAMIC 0.022uF 25V
C149 1-162-294-31 CERAMIC 0.001uF 10% 50V
C150 1-161-494-00 CERAMIC 0.022uF 25V
C151 1-128-551-11 ELECT 22uF 20% 25V
C152 1-162-282-31 CERAMIC 100PF 10% 50V
C154 1-164-159-11 CERAMIC 0.1uF 50V
C155 1-162-294-31 CERAMIC 0.001uF 10% 50V
C156 1-102-516-11 CERAMIC 27PF 5% 50V
C157 1-102-516-11 CERAMIC 27PF 5% 50V
C158 1-104-664-11 ELECT 47uF 20% 16V
C159 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C160 1-126-963-11 ELECT 4.7uF 20% 50V
C161 1-126-963-11 ELECT 4.7uF 20% 50V
C162 1-161-494-00 CERAMIC 0.022uF 25V
C163 1-161-494-00 CERAMIC 0.022uF 25V
C164 1-126-962-11 ELECT 3.3uF 20% 50V
C165 1-162-305-11 CERAMIC 0.0068uF 30% 16V
C177 1-161-494-00 CERAMIC 0.022uF 25V
C179 1-164-206-41 CERAMIC 0.047uF 99% 50V
C185 1-164-159-11 CERAMIC 0.1uF 50V
C186 1-162-294-31 CERAMIC 0.001uF 10% 50V
C187 1-161-494-00 CERAMIC 0.022uF 25V
C188 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C189 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C194 1-162-286-31 CERAMIC 220PF 10% 50V
C195 1-162-286-31 CERAMIC 220PF 10% 50V
C196 1-162-286-31 CERAMIC 220PF 10% 50V
C197 1-162-286-31 CERAMIC 220PF 10% 50V
C198 1-126-959-11 ELECT 0.47uF 20% 50V
C199 1-164-206-41 CERAMIC 0.047uF 99% 50V
C201 1-162-292-31 CERAMIC 680PF 10% 50V
C202 1-162-292-31 CERAMIC 680PF 10% 50V
C203 1-162-292-31 CERAMIC 680PF 10% 50V
C204 1-162-292-31 CERAMIC 680PF 10% 50V
C205 1-162-286-31 CERAMIC 220PF 10% 50V
C206 1-162-286-31 CERAMIC 220PF 10% 50V
C207 1-162-286-31 CERAMIC 220PF 10% 50V
C208 1-162-286-31 CERAMIC 220PF 10% 50V
C209 1-104-664-11 ELECT 47uF 20% 16V
C210 1-104-664-11 ELECT 47uF 20% 16V
C211 1-130-486-00 MYLAR 0.018uF 10% 50V
FRONT H/P MAIN
