Sony HCD-C770 - Chassis Section-1

110
HCD-C770/C990
8-4. CHASSIS SECTION-1
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
151 X-4954-745-1 FOOT SUB ASSY
152 4-240-397-01 POWER BUTTON
153 4-240-410-01 FOOT
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-545-14 SCREW +BTP 3X6 TYPE2 N-S
153
151
152
not supplied
(power SW board)
chassis section-2
#1
#1
#1
#1
#2
not supplied
(SEL board)
not supplied
not supplied
