Sony HCD-C770 - Printed Wiring Board - DVD Board (Conductor Side)

HCD-C770/C990
4343
7-12. PRINTED WIRING BOARD – DVD Board (Conductor Side) – • See page 37 for Circuit Boards Location.
IC604
IC900
IC702
IC808
IC906
IC812
1120
101
IC903
IC904
31
4
5
31
4
IC302
5
IC501
IC706
IC202
IC204
IC215
IC203
IC602
IC003
IC001
IC002
IC603
IC610
IC601
IC600
1
8
16
9
IC608
1
8
16
9
IC303
IC814
1
4
8
5
IC004
IC005
2
13
2
13
2
13
2
13
2
1
3
2
3
1
2
13
2
31
E
EE
128
56 29
2
3
1
E
E
E
E
IC803
IC802
1
4
8
5
1
3
5
4
IC703
+
E
E
E
(US, CND)
(EXCEPT AEP)
E
E
E
E
E
(AEP)
(C990)
E
IC006
E
E
IC905
4
5
1
3
3
1
4
5
IC907
(CONDUCTOR SIDE)
DVD BOARD
1-685-086-
11
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
A
B
C
D
E
F
G
H
I
• Semiconductor
Location
Ref. No. Location
D902 C-13
D903 C-11
D904 C-13
D906 C-12
D907 B-14
IC001 H-5
IC002 H-4
IC003 G-4
IC004 E-2
IC005 D-2
IC006 I-6
IC202 G-8
IC203 G-5
IC204 G-7
IC215 E-6
IC302 D-14
IC303 E-8
IC501 H-13
IC600 F-2
IC601 G-3
IC602 F-4
IC603 H-3
IC604 C-4
IC608 F-3
IC610 G-3
IC702 D-6
IC703 H-9
IC706 F-10
IC802 E-12
IC803 E-12
IC808 C-8
IC812 D-10
IC814 E-9
IC900 C-5
IC903 D-12
IC904 D-13
IC906 C-10
Q001 H-2
Q002 I-2
Q003 H-3
Q004 I-3
Q301 F-12
Q302 G-5
Q900 B-13
Q901 B-13
Q902 B-13
Q903 D-11
Q906 C-12
Q907 D-12
Q908 B-6
Q909 B-6
Q910 B-5
Q911 B-14
Q912 B-14
Q913 B-12
