Sony HCD-C770 - Printed Wiring Boards - AUDIO Section

HCD-C770/C990
5858
7-27. PRINTED WIRING BOARDS – AUDIO Section – • See page 37 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D201 B-2
D202 A-4
D203 A-4
IC201 B-2
IC202 A-5
Q201 E-2
Q205 E-5
Q206 E-5
Q207 E-3
Q208 E-3
Q220 E-2
Q221 E-2
Q222 A-4
Q223 A-3
IC202
IC201
1-685-073-
11
(11)
E
E
E
E
E
E
E
FM/AM TUNER
PACK
AM
COAXIAL
FM
75Ω
E
DVD BOARD
CN002
K
VIDEO BOARD
CN207
R L
AM
AUDIO IN
R LAUDIO OUT
VIDEO IN
VIDEO OUT
Y
R
PB/CB
LAUDIO IN VIDEO IN
P/CR
VIDEO 2
COMPONENT
VIDEO OUT
VIDEO 1
J205
J206
INTERLACE SELECTABLE
SCAN SELECT
SUPPLIED WITH
THE ASSEMBLED
BLOCK
AUDIO BOARD
(COMPONENT SIDE)
AUDIO BOARD
(CONDUCTOR SIDE)
1-685-073-
11
(11)
SEL BOARD
1-685-889-
11
(11)
A
B
C
D
E
F
1 2 3 4 5 6 7
R
AMP BOARD
PIN301
(Page 42)
(Page 60)
(Page 55)
