Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
124
HCD-C770/C990
C241 1-126-965-11 ELECT 22uF 20% 35V
C242 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C243 1-126-157-11 ELECT 10uF 20% 16V
C245 1-126-964-11 ELECT 10uF 20% 50V
C608 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C609 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
< CONNECTOR >
CN201 1-784-733-11 CONNECTOR, FFC 11P
CN202 1-779-566-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN204 1-568-940-11 PIN, CONNECTOR 2P
CN205 1-506-481-11 PIN, CONNECTOR 2P
CN208 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D201 8-719-056-78 DIODE UDZ-TE-17-4.3B (AEP)
D202 8-719-404-50 DIODE MA111-TX
D203 8-719-404-50 DIODE MA111-TX
< IC >
IC201 8-759-557-36 IC BU1924F-E2 (AEP)
IC202 8-759-385-76 IC MC14052 BDR2
< JACK >
J205 1-816-602-11 PIN JACK 6P
(VIDEO 2/COMPONENT VIDEO OUT)
J206 1-816-602-21 PIN JACK 6P (VIDEO 1)
< COIL >
L205 1-469-525-11 INDUCTOR 10uH (AEP)
L206 1-469-525-11 INDUCTOR 10uH
< TRANSISTOR >
Q201 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR (AEP)
Q205 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q206 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q207 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q208 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q220 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q221 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q222 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q223 8-729-901-00 TRANSISTOR DTC124EKA-T146
< RESISTOR >
R201 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(AEP)
R202 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP)
R203 1-216-843-11 METAL CHIP 68K 5% 1/10W
(AEP)
R204 1-216-841-11 METAL CHIP 47K 5% 1/10W
(AEP)
R205 1-216-845-11 METAL CHIP 100K 5% 1/10W
(AEP)
R206 1-216-853-11 METAL CHIP 470K 5% 1/10W
(AEP)
R207 1-216-814-11 METAL CHIP 270 5% 1/10W
(AEP)
R208 1-216-813-11 METAL CHIP 220 5% 1/10W
R209 1-216-813-11 METAL CHIP 220 5% 1/10W
R210 1-216-813-11 METAL CHIP 220 5% 1/10W
R211 1-216-813-11 METAL CHIP 220 5% 1/10W
R212 1-216-813-11 METAL CHIP 220 5% 1/10W
R213 1-216-841-11 METAL CHIP 47K 5% 1/10W
R214 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R215 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R216 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R217 1-216-839-11 METAL CHIP 33K 5% 1/10W
R218 1-216-833-11 METAL CHIP 10K 5% 1/10W
R219 1-216-809-11 METAL CHIP 100 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-839-11 METAL CHIP 33K 5% 1/10W
R223 1-216-833-11 METAL CHIP 10K 5% 1/10W
R224 1-216-809-11 METAL CHIP 100 5% 1/10W
R225 1-216-839-11 METAL CHIP 33K 5% 1/10W
R226 1-216-839-11 METAL CHIP 33K 5% 1/10W
R227 1-216-821-11 METAL CHIP 1K 5% 1/10W
R228 1-216-821-11 METAL CHIP 1K 5% 1/10W
R229 1-216-845-11 METAL CHIP 100K 5% 1/10W
R230 1-216-845-11 METAL CHIP 100K 5% 1/10W
R231 1-218-285-11 RES-CHIP 75 5% 1/10W
R232 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R233 1-216-833-11 METAL CHIP 10K 5% 1/10W
R235 1-216-841-11 METAL CHIP 47K 5% 1/10W
R236 1-216-833-11 METAL CHIP 10K 5% 1/10W
R237 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R238 1-216-833-11 METAL CHIP 10K 5% 1/10W
R239 1-216-821-11 METAL CHIP 1K 5% 1/10W
R241 1-216-841-11 METAL CHIP 47K 5% 1/10W
R242 1-216-833-11 METAL CHIP 10K 5% 1/10W
R243 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R244 1-216-833-11 METAL CHIP 10K 5% 1/10W
R245 1-216-821-11 METAL CHIP 1K 5% 1/10W
R246 1-216-841-11 METAL CHIP 47K 5% 1/10W
R247 1-216-833-11 METAL CHIP 10K 5% 1/10W
R249 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R250 1-216-833-11 METAL CHIP 10K 5% 1/10W
R251 1-218-285-11 RES-CHIP 75 5% 1/10W
R252 1-216-833-11 METAL CHIP 10K 5% 1/10W
R253 1-216-841-11 METAL CHIP 47K 5% 1/10W
R254 1-218-285-11 RES-CHIP 75 5% 1/10W
R290 1-216-853-11 METAL CHIP 470K 5% 1/10W
R291 1-216-853-11 METAL CHIP 470K 5% 1/10W
R292 1-216-821-11 METAL CHIP 1K 5% 1/10W
R293 1-216-821-11 METAL CHIP 1K 5% 1/10W
R294 1-216-815-11 METAL CHIP 330 5% 1/10W
R295 1-216-815-11 METAL CHIP 330 5% 1/10W
< VIBRATOR >
X201 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz) (AEP)
**************************************************************
AUDIO
