Sony HCD-C770 - Page 72

72
HCD-C770/C990
900 mVp-
p
H
750 mVp-
p
H
750 mVp-
p
H
4.3 Vp-p
37 ns
5.3 Vp-
p
43 ns
850 mVp-
p
H
Approx.
100 mVp-p
4.5 Vp-
p
29.5 ns
3 Vp-p
29.5 ns
3.5 Vp-p
7.4 µ s
wa IC701 <znc (LRCK)
wj IC301 yg (TE)ws IC701 <zm/ (XTAL1) es IC206 <zxx (VDAC 3) (NTSC Color Bars Play)
wd IC801 qa (MCKI) wk IC301 yj (FE) ed IC206 <zxb (VDAC 2) (NTSC Color Bars Play)
wf IC801 qd (EXCKO1)
Approx.
50 mVp-p
ea IC206 <zz. (VDAC 4) (NTSC Color Bars Play)
ef IC206 <zx, (VDAC 1) (NTSC Color Bars Play)
wh IC301 ra (EXTAL)
1.6 Vp-
p
50 ns
wl IC303 3 (MO1)
5 Vp-
p
354 ns
wg IC801 ys (PHREFO)
3.7 Vp-
p
37 ns
e; IC303 8 (XTO)
1.3 Vp-
p
H
eg IC206 <zcz (VDAC 0) (NTSC Color Bars Play)
