8
HCD-CL1/CL3
3-2. CASSETTE MECHANISM
3-3. FRONT PANEL
8
Cassette mechanism dec
k
7
Flat cable (9 core)
6
Screw
(
+BVTP 2.6 × 8
)
6
Two screws
(
+BVTP 2.6 × 8
)
5
TC board
4
Two screws
(
+BVTP 3 × 8
)
1
Connector
2 Three s
crews
(
+BVTP 2.6 × 8
)
3
Bracket
(Cassette mechanism)
2 S
crew
(
+BVTP 2.6 × 8
)
1
Screw
(
+BVTP 3 × 8
)
2
Screw
(
+BVTP 3 × 8
)
3
Screw
(
+BVTP 3 × 8
)
6
Front panel
5
Connector
(CN701)
4
Two screws
(
HEXAGON
SOCKET TAPPING
)
