Sony HCD-CL3 - Driver Board; Fitting Base (Stabilizer) Assy, Tray Assy

12
HCD-CL1/CL3
3-9. DRIVER BOARD
2 Screw (BTTP M2.6)
2 Screw (BTTP M2.6)
1 Connector (CN703)
1 Connector (CN704)
1 Connector (CN702)
1 Connector (CN705)
3 DRIVER board
3-10. FITTING BASE (STABILIZER) ASSY, TRAY ASSY
3 Three bosses
3 Three bosses
1 Two screws (BTTP M2.6)
1 Two screws (+BTTP M2.6)
2
2
5 Tray assy
4 Fitting base (STABILIZER) assy
