Sony HCD-CL3 - Front Panel Section

48
HCD-CL1/CL3
8-2. FRONT PANEL SECTION
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
not
supplied
65
65
65
63
62
65
65
56
60
64
55
54
53
52
51
61
51 4-231-633-01 LID (CD) (SILVER)
51 4-231-633-11 LID (CD) (BLACK)
52 4-231-670-01 SPRING (CD)
53 4-231-646-01 KNOB, VOLUME
54 X-4953-315-1 PANEL ASSY, FRONT (SILVER) (CL1:AEP,UK)
54 X-4953-316-1 PANEL ASSY, FRONT (SILVER) (CL1:US)
54 X-4953-317-1 PANEL ASSY, FRONT (SILVER)
(CL1:AUS,E,MX,TW,KR)
54 X-4953-320-1 PANEL ASSY, FRONT (SILVER) (CL3:AEP,UK)
54 X-4953-322-1 PANEL ASSY, FRONT (SILVER) (CL3:MX,KR)
54 X-4953-804-1 PANEL ASSY, FRONT (BLACK) (CL1:US)
55 4-933-134-41 SCREW (+PTPWH 2.6X5)
56 1-679-982-11 RING SWITCH BOARD
60 1-804-260-11 DISPLAY PANEL, LIQUID CRYSTAL
61 4-231-637-01 SHEET, DIFFUSION
62 4-231-636-01 HOLDER, LCD
63 1-679-981-11 BACK LIGHT BOARD
64 A-4475-428-A PANEL BOARD, COMPLETE
65 4-951-620-01 SCREW (2.6X8), +BVTP
