SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• Abbreviation
SP : Singapore model
MX : Mexican model
AR : Argentina model
AUS : Australian model
EE : East European model
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1-674-880-11 AC SWITCH BOARD (DR3:E,SP,AR)
***************
< SWITCH >
S001 1-771-477-11 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
************************************************************
1-674-635-11 AMS BOARD
**********
< LED >
LED616 8-719-304-83 LED SEL2410G (CD, ^)
< RESISTOR >
R663 1-247-835-11 CARBON 1.5K 5% 1/4W
R664 1-247-839-11 CARBON 2.2K 5% 1/4W
R665 1-247-843-11 CARBON 3.3K 5% 1/4W
R666 1-247-847-11 CARBON 4.7K 5% 1/4W
R667 1-249-428-11 CARBON 8.2K 5% 1/4W F
R668 1-249-431-11 CARBON 15K 5% 1/4W
< SWITCH >
S645 1-762-875-11 SWITCH, KEYBOARD (CD, ^)
S646 1-762-875-11 SWITCH, KEYBOARD (CD, p)
S647 1-762-875-11 SWITCH, KEYBOARD (DISC SKIP)
S648 1-762-875-11 SWITCH, KEYBOARD (CD, ))
S649 1-762-875-11 SWITCH, KEYBOARD (CD, 0)
S650 1-762-875-11 SWITCH, KEYBOARD (PLAY MODE)
S651 1-762-875-11 SWITCH, KEYBOARD (REPEAT)
< VARIABLERESISTOR >
VR602 1-475-841-11 ENCODER (AMS)
************************************************************
A-4426-810-A CD DECORD BOARD, COMPLETE
**************************
< CAPACITOR >
C01 1-104-665-11 ELECT 100uF 20% 10V
C02 1-130-489-11 MYLAR 0.033uF 5% 50V
C03 1-162-306-11 CERAMIC 0.01uF 20% 16V
C04 1-130-489-11 MYLAR 0.033uF 5% 50V
C05 1-162-306-11 CERAMIC 0.01uF 20% 16V
C06 1-128-551-11 ELECT 22uF 20% 25V
C07 1-162-203-31 CERAMIC 15PF 5% 50V
C08 1-164-159-11 CERAMIC 0.1uF 50V
C11 1-162-600-11 CERAMIC 0.0047uF 20% 16V
C12 1-162-306-11 CERAMIC 0.01uF 20% 16V
C13 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C14 1-164-206-41 CERAMIC 0.047uF 99% 50V
C15 1-161-494-00 CERAMIC 0.022uF 25V
C16 1-164-159-11 CERAMIC 0.1uF 50V
C17 1-104-665-11 ELECT 100uF 20% 10V
C18 1-104-665-11 ELECT 100uF 20% 10V
C19 1-164-159-11 CERAMIC 0.1uF 50V
C20 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C21 1-164-159-11 CERAMIC 0.1uF 50V
C22 1-164-159-11 CERAMIC 0.1uF 50V
C23 1-164-159-11 CERAMIC 0.1uF 50V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C25 1-130-489-11 MYLAR 0.033uF 5% 50V
C26 1-130-486-00 MYLAR 0.018uF 10% 50V
C27 1-162-199-31 CERAMIC 10PF 5% 50V
C28 1-130-493-00 MYLAR 0.068uF 5% 50V
C29 1-126-962-11 ELECT 3.3uF 20% 50V
C30 1-162-215-31 CERAMIC 47PF 5% 50V
C31 1-164-159-11 CERAMIC 0.1uF 50V
C32 1-164-159-11 CERAMIC 0.1uF 50V
C33 1-104-665-11 ELECT 100uF 20% 10V
C41 1-126-964-11 ELECT 10uF 20% 50V
C42 1-126-964-11 ELECT 10uF 20% 50V
C51 1-126-927-11 ELECT 2200uF 20% 10V
C52 1-164-159-11 CERAMIC 0.1uF 50V
C53 1-162-305-11 CERAMIC 0.0068uF 20% 16V
C54 1-130-483-00 MYLAR 0.01uF 5% 50V
C56 1-137-380-11 FILM 0.47uF 5% 50V
C57 1-162-306-11 CERAMIC 0.01uF 20% 16V
C59 1-162-290-31 CERAMIC 470PF 10% 50V
C60 1-162-286-31 CERAMIC 220PF 10% 50V
C61 1-137-378-11 FILM 0.22uF 5% 50V
C62 1-162-306-11 CERAMIC 0.01uF 20% 16V
C63 1-164-159-11 CERAMIC 0.1uF 50V
C64 1-104-665-11 ELECT 100uF 20% 10V
C65 1-162-294-31 CERAMIC 0.001uF 10% 50V
C66 1-162-294-31 CERAMIC 0.001uF 10% 50V
C67 1-162-294-31 CERAMIC 0.001uF 10% 50V
C68 1-162-294-31 CERAMIC 0.001uF 10% 50V
C69 1-162-294-31 CERAMIC 0.001uF 10% 50V
C70 1-164-159-11 CERAMIC 0.1uF 50V
C71 1-164-159-11 CERAMIC 0.1uF 50V
C72 1-104-665-11 ELECT 100uF 20% 10V
C73 1-162-209-31 CERAMIC 27PF 5% 50V
C74 1-162-209-31 CERAMIC 27PF 5% 50V
C75 1-161-494-00 CERAMIC 0.022uF 25V
C81 1-162-284-31 CERAMIC 150PF 10% 50V
C82 1-162-284-31 CERAMIC 150PF 10% 50V
C83 1-162-292-31 CERAMIC 680PF 10% 50V
C84 1-162-292-31 CERAMIC 680PF 10% 50V
AMSAC SWITCH
CD DECORD
