Sony HCD-DR3 - Cassette Doors Removal; CD Chassis Assembly

8
2-7. CASSETTE DOORS
2-8. CD CHASSIS ASSY
Cassette door (R)
(Note: Four claws are used.
)
Cassette door (L)
(Note: Four claws are used.)
1 Connector
(CN603)
8 Three screws
5 AMS knob
7 Washer
6 Nut
!º Three screws
!¡ CD key board
!™ CD chassis assy
9 AMS board
3 Five screws
2 Connector
(CN606)
4 Remove the
six claws
