Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
44
S606 1-762-875-11 SWITCH, KEYBOARD (TAPE B, ”)
S607 1-762-875-11 SWITCH, KEYBOARD (TAPE B, “)
S608 1-762-875-11 SWITCH, KEYBOARD (TAPE B, p)
S609 1-762-875-11 SWITCH, KEYBOARD (TAPE B, ))
S610 1-762-875-11 SWITCH, KEYBOARD (TAPE B, 0)
S611 1-762-875-11 SWITCH, KEYBOARD (P PAUSE)
S612 1-762-875-11 SWITCH, KEYBOARD (TUNING +)
S613 1-762-875-11 SWITCH, KEYBOARD (TUNING -)
S614 1-762-875-11 SWITCH, KEYBOARD (ROCK)
S615 1-762-875-11 SWITCH, KEYBOARD (POPS)
S616 1-762-875-11 SWITCH, KEYBOARD (JAZZ)
S617 1-762-875-11 SWITCH, KEYBOARD (SALSA)
S618 1-762-875-11 SWITCH, KEYBOARD (FLAT)
S619 1-762-875-11 SWITCH, KEYBOARD (STEREO/MONO)
S620 1-762-875-11 SWITCH, KEYBOARD (DBFB)
S621 1-762-875-11 SWITCH, KEYBOARD (SURROUND)
S622 1-762-875-11 SWITCH, KEYBOARD (FUNCTION)
S623 1-762-875-11 SWITCH, KEYBOARD (POWER)
S624 1-762-875-11 SWITCH, KEYBOARD (CLOCK SET)
S625 1-762-875-11 SWITCH, KEYBOARD (DAIL)
S626 1-762-875-11 SWITCH, KEYBOARD (TIMER REC)
S627 1-762-875-11 SWITCH, KEYBOARD (SLEEP)
S628 1-762-875-11 SWITCH, KEYBOARD (DISPLAY/DEMO)
S629 1-762-875-11 SWITCH, KEYBOARD (SPECTRUM ANALYZER)
S630 1-762-875-11 SWITCH, KEYBOARD (TUNER MEMORY)
S631 1-762-875-11 SWITCH, KEYBOARD (ENTER/NEXT)
S632 1-762-875-11 SWITCH, KEYBOARD (TUNER/BAND)
S633 1-762-875-11 SWITCH, KEYBOARD (TUNING MODE)
S634 1-762-875-11 SWITCH, KEYBOARD (GROONE)
S635 1-762-875-11 SWITCH, KEYBOARD (DIRECTION)
S636 1-762-875-11 SWITCH, KEYBOARD (DOLBY NR)
S637 1-762-875-11 SWITCH, KEYBOARD (r REC)
S638 1-762-875-11 SWITCH, KEYBOARD (CD SYNCHRO)
< ADJUSTABLE RESISTOR >
SFR601 1-228-991-00 RES, ADJ, METAL2.2K
< VIBRATOR >
X601 1-579-743-11 VIBRATOR, CRYSTAL 6MHz
************************************************************
1-674-641-11 H/P BOARD
*********
< JACK >
JK701 1-569-612-11 JACK, MINIATURE (PHONES)
************************************************************
1-674-637-11 LED BOARD
*********
< LED >
D07 8-719-301-44 LED SEL2410E-C-TP
(CASEETTE BOX BACK LIGHT)
D08 8-719-301-44 LED SEL2410E-C-TP
(CASEETTE BOX BACK LIGHT)
D09 8-719-301-44 LED SEL2410E-C-TP
(CASEETTE BOX BACK LIGHT)
D10 8-719-301-44 LED SEL2410E-C-TP
(CASEETTE BOX BACK LIGHT)
< RESISTOR >
R448 1-249-409-11 CARBON 220 5% 1/4W F
(DR3:E,MX,AR/DR330/XB200)
************************************************************
A-4426-407-A MAIN BOARD, COMPLETE (XB200)
*********************
A-4426-408-A MAIN BOARD, COMPLETE (DR3:E,SP,AR)
*********************
A-4426-409-A MAIN BOARD, COMPLETE (DR3:AUS)
*********************
A-4426-410-A MAIN BOARD, COMPLETE (DR3:MX/DR330)
*********************
< CAPACITOR >
C107 1-162-306-11 CERAMIC 0.01uF 20% 16V
(XB200)
C108 1-126-933-11 ELECT 100uF 20% 16V
C113 1-164-159-11 CERAMIC 0.1uF 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-164-206-41 CERAMIC 0.047uF 99% 50V
C116 1-130-467-00 MYLAR 470PF 5% 50V
C117 1-162-206-31 CERAMIC 20PF 5% 50V
C118 1-126-933-11 ELECT 100uF 20% 16V
C120 1-161-494-00 CERAMIC 0.022uF 25V
C121 1-162-211-31 CERAMIC 33PF 5% 50V
C122 1-126-960-11 ELECT 1uF 20% 50V
C123 1-126-959-11 ELECT 0.47uF 20% 50V
C124 1-162-206-31 CERAMIC 20PF 5% 50V
C125 1-126-960-11 ELECT 1uF 20% 50V
C126 1-164-206-41 CERAMIC 0.047uF 99% 50V
C127 1-126-964-11 ELECT 10uF 20% 50V
C128 1-161-494-00 CERAMIC 0.022uF 25V
C129 1-126-964-11 ELECT 10uF 20% 50V
C130 1-137-352-11 FILM 0.033uF 5% 100V
C131 1-137-352-11 FILM 0.033uF 5% 100V
C132 1-137-504-11 FILM 150PF 5% 50V
C133 1-137-504-11 FILM 150PF 5% 50V
C135 1-162-293-31 CERAMIC 820PF 10% 50V
C137 1-126-963-11 ELECT 4.7uF 20% 50V
C138 1-137-397-11 FILM 0.047uF 5% 100V
C139 1-161-494-00 CERAMIC 0.022uF 25V
C140 1-126-933-11 ELECT 100uF 20% 16V
C141 1-161-494-00 CERAMIC 0.022uF 25V
C142 1-126-933-11 ELECT 100uF 20% 16V
C143 1-137-401-11 FILM 0.22uF 5% 100V
C144 1-137-393-11 FILM 0.01uF 5% 100V
C146 1-162-294-31 CERAMIC 0.001uF 10% 50V
C148 1-161-494-00 CERAMIC 0.022uF 25V
C149 1-162-294-31 CERAMIC 0.001uF 10% 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-128-551-11 ELECT 22uF 20% 25V
C152 1-162-282-31 CERAMIC 100PF 10% 50V
C154 1-164-159-11 CERAMIC 0.1uF 50V
C155 1-162-294-31 CERAMIC 0.001uF 10% 50V
C156 1-102-516-11 CERAMIC 27PF 5% 50V
C157 1-102-516-11 CERAMIC 27PF 5% 50V
C158 1-104-664-11 ELECT 47uF 20% 16V
C159 1-162-306-11 CERAMIC 0.01uF 20% 16V
C160 1-126-963-11 ELECT 4.7uF 20% 50V
C161 1-126-963-11 ELECT 4.7uF 20% 50V
FRONT H/P LED MAIN
