Sony HCD-DR3 - Transistor Part Numbers

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
47
D303 8-719-010-73 DIODE UZ-12BSA
D304 8-719-010-45 DIODE UZ-6.2BSA
D305 8-719-911-19 DIODE 1SS133
D306 8-719-911-19 DIODE 1SS133
D307 8-719-010-45 DIODE UZ-6.2BSA
D308 8-719-010-45 DIODE UZ-6.2BSA
D802 8-719-911-19 DIODE 1SS133
D803 8-719-911-19 DIODE 1SS133
D804 8-719-911-19 DIODE 1SS133
D805 8-719-911-19 DIODE 1SS133
D806 8-719-911-19 DIODE 1SS133
D807 8-719-911-19 DIODE 1SS133
D808 8-719-911-19 DIODE 1SS133
D811 8-719-911-19 DIODE 1SS133
D812 8-719-911-19 DIODE 1SS133
< FRONTEND >
FE101 1-693-422-11 FRONT END
< IC >
IC102 8-759-590-14 IC LA1833L
IC103 8-759-590-13 IC LC72131D
IC201 8-759-595-07 IC M62443FP
IC202 8-759-634-51 IC NJM4558D
IC203 8-759-000-49 IC TC4066BP
IC301 8-759-634-51 IC NJM4558D
IC302 8-759-634-51 IC NJM4558D
IC303 8-759-634-51 IC NJM4558D
IC801 8-759-206-23 IC TA7784P
IC802 8-759-545-67 IC TA8135P
IC803 8-752-056-08 IC CXA1551P
< JACK >
JK101 1-694-092-21 TERMINAL BOARD (SPEAKER)(DR3/DR330)
JK101 1-694-126-11 TERMINAL BOARD (SPEAKER)(XB200)
JK201 1-779-688-11 JACK, PIN 6P (MD/VIDEO IN/OUT,PHONO IN)
< COIL >
L104 1-411-901-11 COIL, ANTENNA
L105 1-429-555-11 TRANSFORMER, MW OSC
L106 1-412-507-11 INDUCTOR 47uH
L108 1-412-503-11 INDUCTOR 22uH
L109 1-410-521-11 INDUCTOR 100uH (XB200)
L113 1-412-503-11 INDUCTOR 22uH
L114 1-412-503-11 INDUCTOR 22uH
L301 1-408-096-00 INDUCTOR 470uH
L801 1-410-775-11 INDUCTOR 10mH
L802 1-410-775-11 INDUCTOR 10mH
L803 1-236-147-11 FILTER, LOW PASS
L804 1-236-147-11 FILTER, LOW PASS
L805 1-239-597-11 FILTER, LOW PASS
L806 1-239-597-11 FILTER, LOW PASS
L808 1-408-096-00 INDUCTOR 470uH
L809 1-433-412-11 TRANSFORMER, BIAS OSCILLATION
< TRANSISTOR >
Q101 8-729-015-41 TRANSISTOR 2SC1675-T1
Q108 8-729-041-83 TRANSISTOR 2SK544E
Q114 8-729-026-29 TRANSISTOR 2SJ346
Q116 8-729-194-57 TRANSISTOR 2SC945TP-P
Q117 8-729-194-57 TRANSISTOR 2SC945TP-P
Q201 8-729-194-57 TRANSISTOR 2SC945TP-P
Q202 8-729-194-57 TRANSISTOR 2SC945TP-P
Q203 8-729-194-57 TRANSISTOR 2SC945TP-P
Q204 8-729-194-57 TRANSISTOR 2SC945TP-P
Q205 8-729-026-29 TRANSISTOR 2SJ346
Q206 8-729-194-57 TRANSISTOR 2SC945TP-P
Q207 8-729-194-57 TRANSISTOR 2SC945TP-P
Q208 8-729-194-57 TRANSISTOR 2SC945TP-P
Q209 8-729-194-57 TRANSISTOR 2SC945TP-P
Q210 8-729-026-29 TRANSISTOR 2SJ346
Q301 8-729-194-57 TRANSISTOR 2SC945TP-P
Q302 8-729-194-57 TRANSISTOR 2SC945TP-P
Q303 8-729-194-57 TRANSISTOR 2SC945TP-P
Q304 8-729-194-57 TRANSISTOR 2SC945TP-P
Q305 8-729-224-62 TRANSISTOR 2SK246-GR
Q306 8-729-026-29 TRANSISTOR 2SJ346
Q308 8-729-232-32 TRANSISTOR 2SA965-O/Y(TPE6)
Q309 8-729-140-96 TRANSISTOR 2SC2060-R
Q310 8-729-140-96 TRANSISTOR 2SC2060-R
Q801 8-729-194-57 TRANSISTOR 2SC945TP-P
Q802 8-729-194-57 TRANSISTOR 2SC945TP-P
Q803 8-729-194-57 TRANSISTOR 2SC945TP-P
Q804 8-729-194-57 TRANSISTOR 2SC945TP-P
Q805 8-729-194-57 TRANSISTOR 2SC945TP-P
Q806 8-729-194-57 TRANSISTOR 2SC945TP-P
Q807 8-729-194-57 TRANSISTOR 2SC945TP-P
Q808 8-729-194-57 TRANSISTOR 2SC945TP-P
Q809 8-729-194-57 TRANSISTOR 2SC945TP-P
Q810 8-729-194-57 TRANSISTOR 2SC945TP-P
Q811 8-729-194-57 TRANSISTOR 2SC945TP-P
Q812 8-729-194-57 TRANSISTOR 2SC945TP-P
Q813 8-729-194-57 TRANSISTOR 2SC945TP-P
Q814 8-729-194-57 TRANSISTOR 2SC945TP-P
Q815 8-729-194-57 TRANSISTOR 2SC945TP-P
Q816 8-729-142-46 TRANSISTOR 2SC2001-L1
Q817 8-729-142-46 TRANSISTOR 2SC2001-L1
Q822 8-729-194-57 TRANSISTOR 2SC945TP-P
Q823 8-729-119-76 TRANSISTOR 2SA733TP-P
Q825 8-729-194-57 TRANSISTOR 2SC945TP-P
Q826 8-729-194-57 TRANSISTOR 2SC945TP-P
Q829 8-729-194-57 TRANSISTOR 2SC945TP-P
Q830 8-729-119-76 TRANSISTOR 2SA733TP-P
Q831 8-729-194-57 TRANSISTOR 2SC945TP-P
Q832 8-729-194-57 TRANSISTOR 2SC945TP-P
Q833 8-729-194-57 TRANSISTOR 2SC945TP-P
< RESISTOR >
R104 1-249-409-11 CARBON 220 5% 1/4W F
R105 1-249-417-11 CARBON 1K 5% 1/4W F
R106 1-247-807-11 CARBON 100 5% 1/4W
R106 1-247-849-11 CARBON 5.6K 5% 1/4W
R107 1-249-427-11 CARBON 6.8K 5% 1/4W F
R112 1-247-698-11 CARBON 68 5% 1/4W F
R113 1-249-417-11 CARBON 1K 5% 1/4W F
R114 1-247-871-11 CARBON 47K 5% 1/4W
R115 1-249-417-11 CARBON 1K 5% 1/4W F
R116 1-249-397-11 CARBON 22 5% 1/4W F
R117 1-247-839-11 CARBON 2.2K 5% 1/4W
R118 1-247-807-11 CARBON 100 5% 1/4W
R119 1-249-410-11 CARBON 270 5% 1/4W F
R120 1-247-843-11 CARBON 3.3K 5% 1/4W
R121 1-247-855-11 CARBON 10K 5% 1/4W
MAIN
