Sony HCD-DZ3K - Printed Wiring Board - SPEAKER Board; Schematic Diagram - SPEAKER Board

4747
HCD-DZ3K
HCD-DZ3K
6-22. PRINTED WIRING BOARD – SPEAKER BOARD –
• See page 25 for Circuit Boards Location.
:Uses unleaded solder.
6-23. SCHEMATIC DIAGRAM – SPEAKER BOARD –
SUR R
SUR L FRONT R
SPEAKER
FRONT L CENTER WOOFER
SPEAKER BOARD
12
13
13
(CHASSIS)(CHASSIS)
J
MAIN BOARD
CN3200
(Page 32)
K
MAIN BOARD
CN3300
(Page 32)
I
MAIN BOARD
CN3100
(Page 32)
JW846
JW845
CN303
CN302
JW844
JW843
TB302
C312
EP302
C322 C323
C324
C321
C310
C311
C309
C318 C319
C320
C306
C307
C308
C303
C304C305 C302
C315
C316 C317
C314
C313
C301
EP301
TB301
CN301
JW842
JW841
(CHASSIS)
(CHASSIS)
EP301
EP302
C301
C302
C303
C304
C305
C306
C307
C308
CN302
TB301
CN301
CN303
C309
C310
C311
C312
C313
C314
C315
C316
C317
C318
C319
C320
C321
C322
C323
C324
TB302
EARTH PLATE
EARTH PLATE
1000p
1000p
1000p
1000p
1000p
1000p
1000p
1000p
VH-L 2P
DICS 4P
EH-4P
EH-6P
1000p
1000p
1000p
1000p
10000p
10000p
10000p
10000p
10000p
10000p
10000p
10000p
10000p
10000p
10000p
10000p
DICS 2P
