68
HCD-DZ3K
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. ., uPA. . : µPA. .,
uPB. . : µPB. ., uPC. . : µPC. .,
uPD. . : µPD. .
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference number,
please include the board name.
DDCON FL
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
•Abbreviation
AUS: Australian model
E32 : 110-240V AC area in E model
MX : Mexican model
SP : Singapore model
DDCON BOARD
************
< CAPACITOR >
C800 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C801 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C802 1-119-772-91 ELECT 47uF 20% 35V
C803 1-124-584-00 ELECT 100uF 20% 10V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-069-56 DIODE UDZSTE-176.2B
D804 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-988-61 DIODE 1SS355TE-17
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q801 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R801 1-216-839-11 METAL CHIP 33K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R805 1-216-295-91 SHORT CHIP 0
< TRANSFORMER >
T801 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
A-1177-702-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C435 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C436 1-115-156-11 CERAMIC CHIP 1uF 10V
C806 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-126-157-11 ELECT 10uF 20% 16V
C810 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C812 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C813 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C814 1-126-157-11 ELECT 10uF 20% 16V
C815 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C816 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C817 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C818 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C821 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C822 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C823 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C824 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C825 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C826 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C829 1-124-259-11 ELECT 4.7uF 20% 50V
C832 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN801 1-779-560-21 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CN805 1-794-506-51 CONNECTOR, FFC/FPC 13P
CN811 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
< DIODE >
D431 8-719-988-61 DIODE 1SS355TE-17
D432 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB806 1-414-813-11 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL801 1-519-852-11 FLUORESCENT INDICATOR
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 8-759-643-83 IC uPD16315GB-3BS
< TRANSISTOR >
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R436 1-216-834-11 METAL CHIP 12K 5% 1/10W
R437 1-216-835-11 METAL CHIP 15K 5% 1/10W
R800 1-216-821-11 METAL CHIP 1K 5% 1/10W
To Next Page
