Sony HCD-DZ3K - Page 71

71
HCD-DZ3K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JACK
< CONNECTOR >
CNP802 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< DIODE >
D433 8-719-988-61 DIODE 1SS355TE-17
D470 8-719-988-61 DIODE 1SS355TE-17
D496 6-501-193-01 DIODE 1SS355WTE-17
D497 6-501-193-01 DIODE 1SS355WTE-17
< FERRITE BEAD >
FB410 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB420 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB470 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB471 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB472 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB474 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB475 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB476 1-469-144-21 FERRITE, EMI (SMD) (2012)
< IC >
IC401 8-759-100-96 IC uPC4558G2
IC402 8-759-100-96 IC uPC4558G2
< JACK >
J401 1-819-878-11 JACK (AUDIO IN/MIC1/A.CAL MIC)
J402 1-819-878-11 JACK (MIC2)
< SHORT >
JR811 1-216-864-11 SHORT CHIP 0
JR813 1-216-864-11 SHORT CHIP 0
JR814 1-216-864-11 SHORT CHIP 0
JR815 1-216-864-11 SHORT CHIP 0
JR816 1-216-864-11 SHORT CHIP 0
JR817 1-216-864-11 SHORT CHIP 0
JR901 1-216-864-11 SHORT CHIP 0
JR902 1-216-864-11 SHORT CHIP 0
JR903 1-216-864-11 SHORT CHIP 0
JR904 1-216-864-11 SHORT CHIP 0
JR905 1-216-864-11 SHORT CHIP 0
JR907 1-216-864-11 SHORT CHIP 0
JR908 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q470 1-801-806-11 TR DTC144EKA
Q471 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q472 8-729-048-50 TRANSISTOR 2SK3018-T106
Q473 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q474 8-729-027-24 TRANSISTOR DTA114TKA-T146
Q475 1-801-806-11 TR DTC144EKA
Q476 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q477 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q478 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R402 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R403 1-216-821-11 METAL CHIP 1K 5% 1/10W
R404 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R405 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R410 1-216-845-11 METAL CHIP 100K 5% 1/10W
R411 1-216-817-11 METAL CHIP 470 5% 1/10W
R412 1-216-837-11 METAL CHIP 22K 5% 1/10W
R413 1-216-821-11 METAL CHIP 1K 5% 1/10W
R414 1-216-835-11 METAL CHIP 15K 5% 1/10W
R415 1-216-821-11 METAL CHIP 1K 5% 1/10W
R416 1-216-801-11 METAL CHIP 22 5% 1/10W
R420 1-216-845-11 METAL CHIP 100K 5% 1/10W
R421 1-216-817-11 METAL CHIP 470 5% 1/10W
R422 1-216-837-11 METAL CHIP 22K 5% 1/10W
R423 1-216-821-11 METAL CHIP 1K 5% 1/10W
R424 1-216-821-11 METAL CHIP 1K 5% 1/10W
R431 1-216-864-11 SHORT CHIP 0
R432 1-216-837-11 METAL CHIP 22K 5% 1/10W
R433 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R434 1-216-864-11 SHORT CHIP 0
R435 1-216-857-11 METAL CHIP 1M 5% 1/10W
R440 1-216-845-11 METAL CHIP 100K 5% 1/10W
R441 1-216-817-11 METAL CHIP 470 5% 1/10W
R442 1-216-837-11 METAL CHIP 22K 5% 1/10W
R443 1-216-821-11 METAL CHIP 1K 5% 1/10W
R444 1-216-835-11 METAL CHIP 15K 5% 1/10W
R446 1-216-809-11 METAL CHIP 100 5% 1/10W
R470 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R471 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R472 1-216-819-11 METAL CHIP 680 5% 1/10W
R477 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R478 1-216-813-11 METAL CHIP 220 5% 1/10W
R479 1-216-864-11 SHORT CHIP 0
R480 1-216-804-11 METAL CHIP 39 5% 1/10W
R481 1-216-845-11 METAL CHIP 100K 5% 1/10W
R482 1-216-833-11 METAL CHIP 10K 5% 1/10W
R487 1-216-864-11 SHORT CHIP 0
R488 1-216-845-11 METAL CHIP 100K 5% 1/10W
R490 1-216-864-11 SHORT CHIP 0
R492 1-216-864-11 SHORT CHIP 0
R494 1-216-864-11 SHORT CHIP 0
R496 1-216-833-11 METAL CHIP 10K 5% 1/10W
R821 1-216-864-11 SHORT CHIP 0
R822 1-216-864-11 SHORT CHIP 0
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R853 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R854 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S800 1-418-725-51 ENCODER, ROTARY (12 TYPE)
(VOLUME – +)
S802 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S803 1-762-875-21 SWITCH, KEYBOARD (.)
S804 1-762-875-21 SWITCH, KEYBOARD (X)
S805 1-762-875-21 SWITCH, KEYBOARD (x)
