75
HCD-DZ3K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
✩ New part of EEP ROM (IC1103) on the MAIN board cannot be used.
Therefore, if the mounted MAIN board (A-1191-800-A, etc.) is replaced,
exchange new EEP ROM (IC1103) with that used before the replacement.
D504 6-501-193-01 DIODE 1SS355WTE-17
D505 6-501-193-01 DIODE 1SS355WTE-17
D2001 8-719-058-24 DIODE RB501V-40TE-17
D3071 6-501-193-01 DIODE 1SS355WTE-17
D3072 6-501-193-01 DIODE 1SS355WTE-17
D3073 6-501-193-01 DIODE 1SS355WTE-17
D3111 6-500-885-01 DIODE P6SMBJ33A-5
D3112 6-500-885-01 DIODE P6SMBJ33A-5
D3151 6-500-885-01 DIODE P6SMBJ33A-5
D3152 6-500-885-01 DIODE P6SMBJ33A-5
D3201 6-500-885-01 DIODE P6SMBJ33A-5
D3202 6-500-885-01 DIODE P6SMBJ33A-5
D3251 6-500-885-01 DIODE P6SMBJ33A-5
D3252 6-500-885-01 DIODE P6SMBJ33A-5
D3301 6-500-885-01 DIODE P6SMBJ33A-5
D3302 6-500-885-01 DIODE P6SMBJ33A-5
D3401 6-500-885-01 DIODE P6SMBJ33A-5
D3402 6-500-885-01 DIODE P6SMBJ33A-5
D3551 6-501-193-01 DIODE 1SS355WTE-17
D3552 6-501-193-01 DIODE 1SS355WTE-17
< GROUND TERMINAL BOARD >
EB903 1-537-770-21 TERMINAL BOARD, GROUND
EB1001 1-537-770-21 TERMINAL BOARD, GROUND
EB1002 1-537-770-21 TERMINAL BOARD, GROUND
EB1003 1-537-770-21 TERMINAL BOARD, GROUND
EB1004 1-537-770-21 TERMINAL BOARD, GROUND
EB3001 1-537-770-21 TERMINAL BOARD, GROUND
EB3002 1-537-770-21 TERMINAL BOARD, GROUND
EB3003 1-537-770-21 TERMINAL BOARD, GROUND
EB3004 1-537-770-21 TERMINAL BOARD, GROUND
EB3005 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB500 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB501 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB502 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB503 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB504 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB505 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB506 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB507 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB508 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB509 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1106 1-414-226-21 INDUCTOR, FERRITE BEAD
FB1108 1-414-226-21 INDUCTOR, FERRITE BEAD
FB1111 1-414-226-21 INDUCTOR, FERRITE BEAD
FB3051 1-216-295-91 SHORT CHIP 0
< FLUORESCENT INDICATOR >
FL501 1-234-177-21 FILTER, CHIP EMI
FL502 1-234-177-21 FILTER, CHIP EMI
FL503 1-233-893-21 FILTER, CHIP EMI
FL1101 1-234-177-21 FILTER, CHIP EMI
FL1104 1-234-177-21 FILTER, CHIP EMI
FL1105 1-234-177-21 FILTER, CHIP EMI
FL1106 1-234-177-21 FILTER, CHIP EMI
FL1107 1-234-177-21 FILTER, CHIP EMI
FL1108 1-234-177-21 FILTER, CHIP EMI
< IC >
IC501 6-806-589-01 IC M30622MEP-A76FPU0
IC502 6-702-302-01 IC TK11133CSCL-G
IC511 6-708-922-01 IC PST3635NR
IC516 6-703-547-01 IC TA7805LS
IC1101 6-707-535-01 IC CXD9849R
IC1102 6-806-817-01 IC MX29LV320CBTC70-OBA2-0604UC
(E32, MX)
IC1102 6-806-818-01 IC MX29LV320CBTC70-OBA2-0604CE (AUS)
IC1102 6-806-819-01 IC MX29LV320CBTC70-OBA2-0604GA (SP)
✩ IC1103 not supplied IC BR24L64F-WE2
IC1104 6-709-370-01 IC A2V64S40CTP-G75
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1109 6-707-485-01 IC NJM2885DL1-18 (TE2)
IC1201 6-704-524-01 IC FAN8036L
IC2200 6-707-608-01 IC PCM1803DBR
IC3003 8-759-680-48 IC TC7WH157FK (TE85R)
IC3010 6-705-979-01 IC CXD9788AR
IC3020 6-705-979-01 IC CXD9788AR
IC3030 6-705-979-01 IC CXD9788AR
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 8-759-649-50 IC SN74AHC1GU04DCKR
IC3100 6-708-921-01 IC CXD9883M
IC3150 6-708-921-01 IC CXD9883M
IC3200 6-708-921-01 IC CXD9883M
IC3250 6-708-921-01 IC CXD9883M
IC3300 6-708-921-01 IC CXD9883M
IC3400 6-708-921-01 IC CXD9883M
< SHORT >
JC506 1-216-864-11 SHORT CHIP 0
JC511 1-216-864-11 SHORT CHIP 0 (SP)
JC513 1-216-864-11 SHORT CHIP 0 (AUS)
JC517 1-216-864-11 SHORT CHIP 0 (E32, MX)
< COIL >
L2200 1-414-754-11 INDUCTOR 10uH
L2201 1-216-295-91 SHORT CHIP 0
L3000 1-469-527-91 INDUCTOR 47uH
L3051 1-414-754-11 INDUCTOR 10uH
L3052 1-414-754-11 INDUCTOR 10uH
L3053 1-414-754-11 INDUCTOR 10uH
L3054 1-412-939-11 INDUCTOR 1uH
L3111 1-456-680-11 INDUCTOR 10uH
L3112 1-456-680-11 INDUCTOR 10uH
L3151 1-456-680-11 INDUCTOR 10uH
L3152 1-456-680-11 INDUCTOR 10uH
L3201 1-456-680-11 INDUCTOR 10uH
L3202 1-456-680-11 INDUCTOR 10uH
L3251 1-456-680-11 INDUCTOR 10uH
L3252 1-456-680-11 INDUCTOR 10uH
L3301 1-456-680-11 INDUCTOR 10uH
L3302 1-456-680-11 INDUCTOR 10uH
L3401 1-456-680-11 INDUCTOR 10uH
L3402 1-456-680-11 INDUCTOR 10uH
Ver. 1.1
