Sony HCD-DZ3K - Page 79

79
HCD-DZ3K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R3271 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3272 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3273 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3274 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3275 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3276 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3277 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3301 1-216-809-11 METAL CHIP 100 5% 1/10W
R3302 1-216-809-11 METAL CHIP 100 5% 1/10W
R3303 1-216-797-11 METAL CHIP 10 5% 1/10W
R3304 1-216-864-11 SHORT CHIP 0
R3307 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3315 1-216-797-11 METAL CHIP 10 5% 1/10W
R3316 1-216-797-11 METAL CHIP 10 5% 1/10W
R3319 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3320 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3321 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3322 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3323 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3324 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3326 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3327 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3401 1-216-809-11 METAL CHIP 100 5% 1/10W
R3402 1-216-809-11 METAL CHIP 100 5% 1/10W
R3403 1-216-797-11 METAL CHIP 10 5% 1/10W
R3404 1-216-864-11 SHORT CHIP 0
R3407 1-216-835-11 METAL CHIP 15K 5% 1/10W
R3415 1-216-797-11 METAL CHIP 10 5% 1/10W
R3416 1-216-797-11 METAL CHIP 10 5% 1/10W
R3419 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3420 1-216-136-00 RES-CHIP 2.7 5% 1/8W
R3421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3423 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3424 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3425 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3426 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3427 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3551 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3555 1-216-864-11 SHORT CHIP 0
R4002 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1107 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1108 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1111 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1112 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1113 1-234-371-21 RES, NETWORK 47 (1005X4)
RB1114 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1115 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X502 1-795-058-21 VIBRATOR, CERAMIC 5MHz
X1102 1-813-539-11 QUARTZ CRYSTAL UNIT 27MHz
X3051 1-795-660-21 QUARTZ CRYSTAL UNIT 49.152MHz
************************************************************
MS-203 BOARD
*************
< CONNECTOR >
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
< SWITCH >
S001 1-786-693-11 SWITCH, DETECTION
************************************************************
A-1146-091-A POWER BOARD, COMPLETE (MX)
A-1159-363-A POWER BOARD, COMPLETE (E32)
A-1178-742-A POWER BOARD, COMPLETE (SP, AUS)
***********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3 (EXCEPT MX)
< CAPACITOR >
0 C901 1-165-529-11 MYLAR 0.22uF 10 275V
0 C902 1-165-529-11 MYLAR 0.22uF 10 275V
0 C903 1-112-331-11 ELECT (BLOCK) 1000uF 20% 250V
(MX)
0 C903 1-112-333-11 ELECT (BLOCK) 330uF 20% 450V
(EXCEPT MX)
0 C905 1-112-334-91 FILM 0.01uF 5% 400V
(MX)
0 C905 1-112-335-91 FILM 0.0033uF 5% 400V
(EXCEPT MX)
0 C906 1-117-815-11 FILM 1000PF 3% 1.5KV
(EXCEPT MX)
0 C906 1-117-828-11 FILM 3300PF 3% 1.5KV
(MX)
0 C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(EXCEPT MX)
0 C907 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
(MX)
0 C908 1-107-909-11 ELECT 47uF 20% 50V
0 C909 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
0 C910 1-107-906-11 ELECT 10uF 20% 50V
(MX)
0 C910 1-107-909-11 ELECT 47uF 20% 50V
(E32)
0 C910 1-126-965-91 ELECT 22uF 20% 50V
(SP, AUS)
0 C911 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C913 1-117-693-11 CERAMIC 100PF 10% 250V
0 C918 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C920 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C922 1-128-560-11 ELECT 22uF 20% 100V
0 C923 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
0 C924 1-126-961-11 ELECT 2.2uF 20% 50V
0 C925 1-107-974-81 CERAMIC 47PF 5% 2KV
0 C928 1-113-896-11 CERAMIC 220PF 10% 250V
(MX)
MAIN MS-203 POWER
