HCD-DZ3K
Ref. No. Part No. Description Remark
SPEAKER SW
C316 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C317 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C318 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C319 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C320 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C321 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C322 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C323 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C324 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
* CN301 1-564-519-11 PLUG, CONNECTOR 4P
CN302 1-818-651-11 PIN, CONNECTOR 2P
* CN303 1-564-521-11 PLUG, CONNECTOR 6P
< EARTH TERMINAL >
EP301 1-537-770-21 TERMINAL BOARD, GROUND
EP302 1-537-770-21 TERMINAL BOARD, GROUND
< TERMINAL >
TB301 1-780-344-11 TERMINAL BOARD (SPEAKER) 4P
(FRONT R, FRONT L, CENTER, WOOFER)
TB302 1-780-343-11 TERMINAL BOARD (SPEAKER) 2P
(SUR R, SUR L)
************************************************************
SW BOARD
*********
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (?/1)
************************************************************
MISCELLANEOUS
**************
3 1-693-702-11 TUNER (FM/AM) (TM10SE)
8 1-828-952-11 WIRE(FLAT TYPE)(9 CORE)
65 1-828-384-11 WIRE(FLAT TYPE)(23 CORE)
66 1-828-325-11 WIRE(FLAT TYPE)(13 CORE)
104 1-787-331-11 FAN, D.C.
0 105 1-827-226-41 CORD, POWER (MX)
0 105 1-829-259-11 CORD, POWER (AUS)
0 105 1-830-188-11 CORD, POWER (E32, SP)
109 1-828-292-11 WIRE(FLAT TYPE)(5 CORE)
110 1-828-332-11 WIRE(FLAT TYPE)(13 CORE)
111 1-828-300-11 WIRE(FLAT TYPE)(7 CORE)
112 1-828-330-11 WIRE(FLAT TYPE)(13 CORE)
0 507 8-820-290-02 OPTICAL PICK-UP(KHM-310CAA/C2RP)
508 1-828-773-51 WIRE(FLAT TYPE)(24 CORE)
0 F901 1-532-325-00 FUSE, TIME-LAG (T6.3A/250V) (SP, AUS)
0 F901 1-532-749-11 FUSE, GLASS CYLINDRICAL (DIA.5) (8A/125V)
(MX)
0 F901 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8A/250V)
(E32)
