HCD-EC55/EC77/GX99
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN501 1-815-449-11 PIN, CONNECTOR (PWB) 8P
< TERMINAL >
ET501 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC501 8-759-100-96 IC uPC4558G2
IC502 8-759-100-96 IC uPC4558G2
< JUMPER RESISTOR >
JR501 1-216-864-11 SHORT CHIP 0
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
JR504 1-216-295-91 SHORT CHIP 0
< COIL >
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R502 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R503 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R504 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R505 1-216-835-11 METAL CHIP 15K 5% 1/10W
R506 1-216-835-11 METAL CHIP 15K 5% 1/10W
R507 1-216-851-11 METAL CHIP 330K 5% 1/10W
R508 1-216-851-11 METAL CHIP 330K 5% 1/10W
R509 1-216-811-11 METAL CHIP 150 5% 1/10W
R510 1-216-811-11 METAL CHIP 150 5% 1/10W
R511 1-216-845-11 METAL CHIP 100K 5% 1/10W
R512 1-216-845-11 METAL CHIP 100K 5% 1/10W
R513 1-216-845-11 METAL CHIP 100K 5% 1/10W
R514 1-216-845-11 METAL CHIP 100K 5% 1/10W
R515 1-216-864-11 SHORT CHIP 0
R516 1-216-864-11 SHORT CHIP 0
R517 1-216-821-11 METAL CHIP 1K 5% 1/10W
R518 1-216-821-11 METAL CHIP 1K 5% 1/10W
R519 1-216-841-11 METAL CHIP 47K 5% 1/10W
R520 1-216-841-11 METAL CHIP 47K 5% 1/10W
R521 1-216-841-11 METAL CHIP 47K 5% 1/10W
R522 1-216-841-11 METAL CHIP 47K 5% 1/10W
R523 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R524 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R525 1-216-851-11 METAL CHIP 330K 5% 1/10W
R526 1-216-851-11 METAL CHIP 330K 5% 1/10W
R527 1-216-851-11 METAL CHIP 330K 5% 1/10W
R528 1-216-851-11 METAL CHIP 330K 5% 1/10W
R529 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R530 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R531 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R532 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R533 1-216-837-11 METAL CHIP 22K 5% 1/10W
R534 1-216-835-11 METAL CHIP 15K 5% 1/10W
R535 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R536 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R537 1-216-833-11 METAL CHIP 10K 5% 1/10W
R538 1-216-833-11 METAL CHIP 10K 5% 1/10W
R539 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R540 1-216-805-11 METAL CHIP 47 5% 1/10W
R541 1-216-805-11 METAL CHIP 47 5% 1/10W
R543 1-216-809-11 METAL CHIP 100 5% 1/10W
R544 1-216-809-11 METAL CHIP 100 5% 1/10W
R545 1-216-817-11 METAL CHIP 470 5% 1/10W
R546 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S501 1-762-369-11 SWITCH, SLIDE (REC/PB SW)
*************************************************************
HI-AMP BOARD
*************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C107 1-126-947-11 ELECT 47uF 20% 35V
C108 1-126-947-11 ELECT 47uF 20% 35V
C109 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C110 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C111 1-126-968-11 ELECT 100uF 20% 50V
(EC55/EC77: EXCEPT US,CND)
C111 1-128-576-11 ELECT 100uF 20% 63V
(EC77: US, CND/GX99)
C113 1-126-968-11 ELECT 100uF 20% 50V
(EC55/EC77: EXCEPT US,CND)
C113 1-128-576-11 ELECT 100uF 20% 63V
(EC77: US, CND/GX99)
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC77/GX99)
C116 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EC55)
C118 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC55)
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EC77/GX99)
C119 1-216-864-11 SHORT CHIP 0 (EC55)
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(EC77/GX99)
C120 1-216-864-11 SHORT CHIP 0 (EC55)
C151 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C152 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C153 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
* CN101 1-569-505-11 PIN, CONNECTOR 10P
DECK HI-AMP
