66
HCD-EC55/EC77/GX99
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< DIODE >
D121 6-501-730-01 DIODE MAZ8051GMLS0 (EC55)
D151 6-500-335-01 DIODE MC2838-T112-1
D152 8-719-404-50 DIODE MA111-TX
< IC >
IC101 6-705-620-01 IC STK433-060 (EC55)
IC101 6-705-621-01 IC STK433-070 (EC77: EXCEPT US,CND)
IC102 6-600-580-01 IC STK433-090-E (EC77: US, CND/GX99)
< TRANSISTOR >
Q101 8-729-600-22 TRANSISTOR 2SA1235-F (EC55)
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q151 6-551-270-01 TRANSISTOR 2SA2026
Q152 6-551-270-01 TRANSISTOR 2SA2026
< RESISTOR >
R101 1-216-813-11 METAL CHIP 220 5% 1/10W
(EC77: US, CND/GX99)
R101 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(EC77: E2, E3, E51, MX)
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC55/EC77: AEP, RU)
R102 1-216-813-11 METAL CHIP 220 5% 1/10W
(EC77: US, CND/GX99)
R102 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(EC77: E2, E3, E51, MX)
R102 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC55/EC77: AEP, RU)
R103 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EC55)
R103 1-216-834-11 METAL CHIP 12K 5% 1/10W
(EC77: AEP, RU)
R103 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EC77: EXCEPT AEP,RU/GX99)
R104 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EC55)
R104 1-216-834-11 METAL CHIP 12K 5% 1/10W
(EC77: AEP, RU)
R104 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EC77: EXCEPT AEP,RU/GX99)
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-841-11 METAL CHIP 47K 5% 1/10W
R107 1-216-821-11 METAL CHIP 1K 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
(EC55)
R109 1-216-864-11 SHORT CHIP 0 (EC77/GX99)
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
(EC55)
R110 1-216-864-11 SHORT CHIP 0 (EC77/GX99)
R111 1-216-841-11 METAL CHIP 47K 5% 1/10W
R112 1-216-841-11 METAL CHIP 47K 5% 1/10W
R119 1-216-813-11 METAL CHIP 220 5% 1/10W
R120 1-216-813-11 METAL CHIP 220 5% 1/10W
R121 1-216-813-11 METAL CHIP 220 5% 1/10W
R122 1-216-813-11 METAL CHIP 220 5% 1/10W
R123 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC55)
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC55)
R125 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EC55)
R126 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC55)
R127 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC55)
R128 1-216-833-11 METAL CHIP 10K 5% 1/10W
R129 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-247-807-31 CARBON 100 5% 1/4W
(EC55: AEP, UK/EC77: AEP, RU)
0 R151 1-216-361-31 METAL OXIDE 0.22 5% 2W F
0 R152 1-216-361-31 METAL OXIDE 0.22 5% 2W F
R155 1-216-813-11 METAL CHIP 220 5% 1/10W
R156 1-216-813-11 METAL CHIP 220 5% 1/10W
R159 1-216-833-11 METAL CHIP 10K 5% 1/10W
R160 1-216-833-11 METAL CHIP 10K 5% 1/10W
R161 1-216-833-11 METAL CHIP 10K 5% 1/10W
R162 1-216-833-11 METAL CHIP 10K 5% 1/10W
R165 1-216-833-11 METAL CHIP 10K 5% 1/10W
R166 1-216-833-11 METAL CHIP 10K 5% 1/10W
R167 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R168 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
JACK BOARD
**********
< CAPACITOR >
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C402 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C403 1-216-837-11 METAL CHIP 22K 5% 1/10W
C404 1-216-837-11 METAL CHIP 22K 5% 1/10W
C405 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C406 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< JACK >
J401 1-566-822-51 JACK (AUDIO IN)
J402 1-815-629-21 JACK (PHONES)
*************************************************************
KEY-CD BOARD
************
< RESISTOR >
R407 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R410 1-216-837-11 METAL CHIP 22K 5% 1/10W
R411 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
SW306 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
SW307 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
SW308 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
SW309 1-762-875-21 SWITCH, KEYBOARD (Z)
SW310 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
*************************************************************
HI-AMP JACK KEY-CD
Ver. 1.2
