Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R104 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EC55)
R104 1-216-834-11 METAL CHIP 12K 5% 1/10W
(EC77: AEP, RU)
R104 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EC77: EXCEPT AEP,RU/GX99)
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-841-11 METAL CHIP 47K 5% 1/10W
R107 1-216-821-11 METAL CHIP 1K 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
(EC55)
R109 1-216-864-11 SHORT CHIP 0 (EC77/GX99)
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
(EC55)
R110 1-216-864-11 SHORT CHIP 0 (EC77/GX99)
R111 1-216-841-11 METAL CHIP 47K 5% 1/10W
R112 1-216-841-11 METAL CHIP 47K 5% 1/10W
R119 1-216-813-11 METAL CHIP 220 5% 1/10W
R120 1-216-813-11 METAL CHIP 220 5% 1/10W
R121 1-216-813-11 METAL CHIP 220 5% 1/10W
R122 1-216-813-11 METAL CHIP 220 5% 1/10W
R123 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC55)
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC55)
R125 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EC55)
R126 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC55)
R127 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC55)
R128 1-216-833-11 METAL CHIP 10K 5% 1/10W
R129 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-247-807-31 CARBON 100 5% 1/4W
(EC55: AEP, UK, KR/EC77: AEP, RU)
0 R151 1-216-361-31 METAL OXIDE 0.22 5% 2W F
0 R152 1-216-361-31 METAL OXIDE 0.22 5% 2W F
R155 1-216-813-11 METAL CHIP 220 5% 1/10W
R156 1-216-813-11 METAL CHIP 220 5% 1/10W
R159 1-216-833-11 METAL CHIP 10K 5% 1/10W
R160 1-216-833-11 METAL CHIP 10K 5% 1/10W
R161 1-216-833-11 METAL CHIP 10K 5% 1/10W
R162 1-216-833-11 METAL CHIP 10K 5% 1/10W
R165 1-216-833-11 METAL CHIP 10K 5% 1/10W
R166 1-216-833-11 METAL CHIP 10K 5% 1/10W
R167 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R168 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
JACK BOARD
**********
< CAPACITOR >
C401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C402 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C403 1-216-837-11 METAL CHIP 22K 5% 1/10W
C404 1-216-837-11 METAL CHIP 22K 5% 1/10W
C405 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C406 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< JACK >
J401 1-566-822-51 JACK (AUDIO IN)
J402 1-815-629-21 JACK (PHONES)
*************************************************************
KEY-CD BOARD
************
< RESISTOR >
R407 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R410 1-216-837-11 METAL CHIP 22K 5% 1/10W
R411 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
SW306 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
SW307 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
SW308 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
SW309 1-762-875-21 SWITCH, KEYBOARD (Z)
SW310 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
*************************************************************
KEY-LEFT BOARD
**************
< CONNECTOR >
CN401 1-815-552-11 PIN, CONNECTOR (PWB) 4P
< LED >
LED302 6-501-483-01 DIODE SLR-325VCT31P
< RESISTOR >
R404 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
SW301 1-762-875-21 SWITCH, KEYBOARD (?/1)
SW302 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
*************************************************************
KEY-RIGHT BOARD
***************
< CONNECTOR >
CN403 1-815-550-11 PIN, CONNECTOR (PWB) 2P
< RESISTOR >
R414 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R415 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R416 1-216-833-11 METAL CHIP 10K 5% 1/10W
R417 1-216-837-11 METAL CHIP 22K 5% 1/10W
R418 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
SW314 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
SW315 1-762-875-21 SWITCH, KEYBOARD ( +)
HI-AMP JACK KEY-CD KEY-LEFT KEY-RIGHT
