18
HCD-EC55/EC77/GX99
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SW316 1-762-875-21 SWITCH, KEYBOARD ( –)
SW317 1-762-875-21 SWITCH, KEYBOARD (DSGX)
SW318 1-762-875-21 SWITCH, KEYBOARD (EQ)
*************************************************************
LOW-AMP BOARD (EC77/GX99)
***************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C104 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C107 1-126-947-11 ELECT 47uF 20% 35V
C108 1-126-947-11 ELECT 47uF 20% 35V
C109 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C110 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C111 1-126-968-11 ELECT 100uF 20% 50V
(EC77:EXCEPT US, CND)
C111 1-128-576-11 ELECT 100uF 20% 63V
(EC77: US, CND/GX99)
C113 1-126-968-11 ELECT 100uF 20% 50V
(EC77:EXCEPT US, CND)
C113 1-128-576-11 ELECT 100uF 20% 63V
(EC77: US, CND/GX99)
C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C116 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C118 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C119 1-216-864-11 SHORT CHIP 0
C120 1-216-864-11 SHORT CHIP 0
C151 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C152 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C153 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C154 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C155 1-165-621-91 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
* CN101 1-569-505-11 PIN, CONNECTOR 10P
< DIODE >
D121 6-501-730-01 DIODE MAZ8051GMLS0
D151 6-500-335-01 DIODE MC2838-T112-1
D152 8-719-404-50 DIODE MA111-TX
< IC >
IC101 6-705-621-01 IC STK433-070 (EC77: EXCEPT US, CND)
IC102 6-600-580-01 IC STK433-090-E (EC77: US, CND/GX99)
< TRANSISTOR >
Q101 8-729-600-22 TRANSISTOR 2SA1235-F
Q102 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q151 6-551-270-01 TRANSISTOR 2SA2026
Q152 6-551-270-01 TRANSISTOR 2SA2026
< RESISTOR >
R101 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EC77: US, CND/GX99)
R101 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(EC77: E2, E3, E51, MX, AR, AUS)
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC77: AEP, RU)
R102 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EC77: US, CND/GX99)
R102 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
(EC77: E2, E3, E51, MX, AR, AUS)
R102 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC77: AEP, RU)
R103 1-216-834-11 METAL CHIP 12K 5% 1/10W
(EC77: AEP, RU)
R103 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EC77: E2, E3, E51, MX, AR, AUS)
R104 1-216-834-11 METAL CHIP 12K 5% 1/10W
(EC77: AEP, RU)
R104 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EC77: E2, E3, E51, MX, AR, AUS)
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-841-11 METAL CHIP 47K 5% 1/10W
R107 1-216-821-11 METAL CHIP 1K 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-864-11 SHORT CHIP 0
R111 1-216-841-11 METAL CHIP 47K 5% 1/10W
R112 1-216-841-11 METAL CHIP 47K 5% 1/10W
R119 1-216-813-11 METAL CHIP 220 5% 1/10W
R120 1-216-813-11 METAL CHIP 220 5% 1/10W
R121 1-216-813-11 METAL CHIP 220 5% 1/10W
R122 1-216-813-11 METAL CHIP 220 5% 1/10W
R123 1-216-841-11 METAL CHIP 47K 5% 1/10W
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R125 1-216-845-11 METAL CHIP 100K 5% 1/10W
R126 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R127 1-216-833-11 METAL CHIP 10K 5% 1/10W
R128 1-216-833-11 METAL CHIP 10K 5% 1/10W
R129 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-247-807-31 CARBON 100 5% 1/4W
(EC77: AEP, RU)
0 R151 1-216-361-31 METAL OXIDE 0.22 5% 2W F
0 R152 1-216-361-31 METAL OXIDE 0.22 5% 2W F
R155 1-216-813-11 METAL CHIP 220 5% 1/10W
R156 1-216-813-11 METAL CHIP 220 5% 1/10W
R159 1-216-833-11 METAL CHIP 10K 5% 1/10W
R160 1-216-833-11 METAL CHIP 10K 5% 1/10W
R161 1-216-833-11 METAL CHIP 10K 5% 1/10W
R162 1-216-833-11 METAL CHIP 10K 5% 1/10W
R165 1-216-833-11 METAL CHIP 10K 5% 1/10W
R166 1-216-833-11 METAL CHIP 10K 5% 1/10W
R167 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R168 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
KEY-RIGHT LOW-AMP
Ver. 1.2
