Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69i/EC79i/EC99i
64
R797 1-216-841-11 METAL CHIP 47K 5% 1/10W
R798 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R799 1-216-818-11 METAL CHIP 560 5% 1/10W
R801 1-216-809-11 METAL CHIP 100 5% 1/10W
R802 1-216-801-11 METAL CHIP 22 5% 1/10W
R803 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R804 1-216-801-11 METAL CHIP 22 5% 1/10W
R805 1-216-853-11 METAL CHIP 470K 5% 1/10W
R806 1-216-841-11 METAL CHIP 47K 5% 1/10W
R807 1-216-837-11 METAL CHIP 22K 5% 1/10W
R808 1-216-801-11 METAL CHIP 22 5% 1/10W
R809 1-216-809-11 METAL CHIP 100 5% 1/10W
R810 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R811 1-216-845-11 METAL CHIP 100K 5% 1/10W
R812 1-216-841-11 METAL CHIP 47K 5% 1/10W
R813 1-216-853-11 METAL CHIP 470K 5% 1/10W
R814 1-216-837-11 METAL CHIP 22K 5% 1/10W
R815 1-216-833-11 METAL CHIP 10K 5% 1/10W
R816 1-216-821-11 METAL CHIP 1K 5% 1/10W
R817 1-216-841-11 METAL CHIP 47K 5% 1/10W
R818 1-216-833-11 METAL CHIP 10K 5% 1/10W
R819 1-216-839-11 METAL CHIP 33K 5% 1/10W
R820 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R821 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R822 1-216-809-11 METAL CHIP 100 5% 1/10W
R823 1-216-833-11 METAL CHIP 10K 5% 1/10W
R824 1-216-817-11 METAL CHIP 470 5% 1/10W
R825 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R826 1-216-821-11 METAL CHIP 1K 5% 1/10W
R827 1-216-845-11 METAL CHIP 100K 5% 1/10W
R829 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R830 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R831 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R832 1-216-857-11 METAL CHIP 1M 5% 1/10W
R836 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R837 1-216-845-11 METAL CHIP 100K 5% 1/10W
R838 1-216-837-11 METAL CHIP 22K 5% 1/10W
R839 1-216-797-11 METAL CHIP 10 5% 1/10W
R840 1-216-864-11 SHORT CHIP 0
R841 1-216-833-11 METAL CHIP 10K 5% 1/10W
R842 1-216-864-11 SHORT CHIP 0
R843 1-216-845-11 METAL CHIP 100K 5% 1/10W
R844 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R845 1-216-864-11 SHORT CHIP 0
R846 1-216-797-11 METAL CHIP 10 5% 1/10W
R847 1-216-864-11 SHORT CHIP 0
R860 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC99i)
R861 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC99i)
R862 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC99i)
R863 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC99i)
R864 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC99i)
R865 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EC99i)
R866 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC99i)
R867 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(EC99i)
R868 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(EC99i)
R869 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC99i)
R870 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC99i)
R875 1-216-864-11 SHORT CHIP 0 (EC69i/EC79i)
R876 1-216-805-11 METAL CHIP 47 5% 1/10W
R878 1-216-864-11 SHORT CHIP 0 (EC99i)
R880 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EC99i)
R881 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC99i)
R882 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EC99i)
R883 1-216-842-11 METAL CHIP 56K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R883 1-216-843-11 METAL CHIP 68K 5% 1/10W
(EC79i: US, CND)
R883 1-216-844-11 METAL CHIP 82K 5% 1/10W
(EC69i)
R884 1-216-864-11 SHORT CHIP 0
< RELAY >
RY601 1-755-307-21 RELAY (EC79i/EC99i)
RY602 1-755-307-21 RELAY
RY701 1-755-307-21 RELAY (EC99i)
< TRANSFORMER >
T801 1-433-741-11 TRANSFORMER, IF
< TERMINAL >
TB601 1-780-685-11 TERMINAL BOARD (SPEAKER HIGH FREQ.
IMPEDANCE: USE 8Ω) (EC79i/EC99i)
TB602 1-780-314-11 TERMINAL BOARD (SPEAKER IMPEDANCE:
USE 6Ω) (EC69i)
TB602 1-780-314-11 TERMINAL BOARD (SPEAKER LOW FREQ.
IMPEDANCE: USE 8Ω) (EC79i/EC99i)
TB603 1-780-684-11 TERMINAL BOARD, 2P (SUBWOOFER
IMPEDANCE: USE 4Ω) (EC99i)
< VIBRATOR >
X801 1-813-917-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
A-1599-065-A PANEL BOARD, COMPLETE (EC99i: US, CND)
A-1599-078-A PANEL BOARD, COMPLETE (EC99i: AUS)
A-1599-084-A PANEL BOARD, COMPLETE (EC79i: US, CND)
A-1599-090-A PANEL BOARD, COMPLETE (EC79i: UK)
A-1599-094-A PANEL BOARD, COMPLETE (EC79i: AUS)
A-1599-116-A PANEL BOARD, COMPLETE (EC69i: US, CND)
A-1599-133-A PANEL BOARD, COMPLETE (EC69i: UK)
A-1599-136-A PANEL BOARD, COMPLETE (EC69i: AUS)
A-1731-204-A PANEL BOARD, COMPLETE (EC99i: UK)
*********************
2-649-178-01 PLATE, LIGHT GUIDE
2-649-179-01 SHEET (LCD)
2-665-175-01 SHEET (REFLECTOR)
< CAPACITOR >
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-104-658-91 ELECT 100uF 20% 10V
MAIN PANEL
Ver. 1.1
