Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69i/EC79i/EC99i
6565
C303 1-126-964-11 ELECT 10uF 20% 50V
C304 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-104-655-91 ELECT 470uF 20% 6.3V
C313 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C319 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C320 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C330 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C336 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C338 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C340 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C351 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EC79i: UK, AUS/EC99i)
C352 1-126-964-11 ELECT 10uF 20% 50V
(EC79i: UK, AUS/EC99i)
C353 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EC79i: UK, AUS/EC99i)
C354 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC69i: UK, AUS/EC79i: UK, AUS/EC99i: UK, AUS)
C355 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(EC69i: UK, AUS/EC79i: UK, AUS/EC99i: UK, AUS)
C357 1-126-965-91 ELECT 22uF 20% 50V
(EC79i: UK, AUS/EC99i)
C434 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C669 1-126-923-91 ELECT 220uF 20% 10V
C671 1-126-933-11 ELECT 100uF 20% 16V
C673 1-126-925-91 ELECT 470uF 20% 10V
C675 1-126-960-11 ELECT 1uF 20% 50V
C676 1-126-960-11 ELECT 1uF 20% 50V
C703 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C704 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
< CONNECTOR >
CN301 1-784-747-11 CONNECTOR, FFC 25P
CN302 1-784-727-11 CONNECTOR, FFC 5P (EC79i: UK, AUS/EC99i)
CN303 1-824-027-21 HOLDER, CABLE 3P
CN608 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
< DIODE >
D301 6-501-722-01 DIODE MAZ8043GMLS0
D302 6-501-817-01 DIODE MA2J1110GLS0
D303 6-500-334-01 DIODE MC2836-T112-1
D304 6-501-817-01 DIODE MA2J1110GLS0
D305 6-501-479-01 LED 1L0341Y23E0CA602 (STANDBY)
(EC69i/EC79i: US, CND)
D305 6-502-773-01 LED SELG2WA10C LF62 (STANDBY)
(EC79i: UK, AUS/EC99i)
D306 6-501-582-01 DIODE 1N4002-A2 (EC79i: UK, AUS/EC99i)
D307 6-501-817-01 DIODE MA2J1110GLS0 (EC79i: UK, AUS/EC99i)
D618 6-501-719-01 DIODE MAZ8039GHLS0
D619 6-501-582-01 DIODE 1N4002-A2
D620 6-501-582-01 DIODE 1N4002-A2
< IC >
IC301 A-1711-704-A IC MB90F830PF-GE1 (for SERVICE)
(EC79i: UK, AUS/EC99i)
IC301 A-1711-705-A
IC MB90F830PF-GE1 (for SERVICE)
(EC69i/EC79i: US, CND)
IC302 6-600-349-21 IC NJL23H400A
IC303 8-759-598-69 IC BA6956AN (EC79i: UK, AUS/EC99i)
< LIQUID CRYSTAL DISPLAY >
LCD301 1-802-840-11 DISPLA
Y PANEL, LIQUID CRYSTAL
(EC69i/EC79i: US, CND)
LCD301 1-802-841-11 DISPLAY PANEL, LIQUID CRYSTAL
(EC79i: UK, AUS/EC99i)
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-037-13 TRANSISTOR KTA1271Y
Q303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q307 8-729-038-28 TRANSISTOR RT1N441C-TP-1
(EC79i: UK, AUS/EC99i)
Q622 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q624 8-729-036-86 TRANSISTOR KTC3203Y-AT
< RESISTOR >
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
R302 1-216-809-11 METAL CHIP 100 5% 1/10W
R303 1-216-809-11 METAL CHIP 100 5% 1/10W
R304 1-216-809-11 METAL CHIP 100 5% 1/10W
R305 1-216-809-11 METAL CHIP 100 5% 1/10W
R306 1-216-809-11 METAL CHIP 100 5% 1/10W
R307 1-216-809-11 METAL CHIP 100 5% 1/10W
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
R309 1-216-809-11 METAL CHIP 100 5% 1/10W
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
R311 1-216-809-11 METAL CHIP 100 5% 1/10W
R312 1-216-809-11 METAL CHIP 100 5% 1/10W
R313 1-216-809-11 METAL CHIP 100 5% 1/10W
R314 1-216-809-11 METAL CHIP 100 5% 1/10W
R315 1-216-809-11 METAL CHIP 100 5% 1/10W
R317 1-216-809-11 METAL CHIP 100 5% 1/10W
R318 1-216-809-11 METAL CHIP 100 5% 1/10W
R319 1-216-809-11 METAL CHIP 100 5% 1/10W
R320 1-216-809-11 METAL CHIP 100 5% 1/10W
R321 1-216-809-11 METAL CHIP 100 5% 1/10W
R322 1-216-809-11 METAL CHIP 100 5% 1/10W
R323 1-216-809-11 METAL CHIP 100 5% 1/10W
R324 1-216-809-11 METAL CHIP 100 5% 1/10W
R325 1-216-797-11 METAL CHIP 10 5% 1/10W
R326 1-216-809-11 METAL CHIP 100 5% 1/10W
R327 1-216-809-11 METAL CHIP 100 5% 1/10W
R328 1-216-833-11 METAL CHIP 10K 5% 1/10W
R329 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R330 1-216-819-11 METAL CHIP 680 5% 1/10W
R331 1-216-845-11 METAL CHIP 100K 5% 1/10W
R332 1-216-833-11 METAL CHIP 10K 5% 1/10W
R333 1-216-845-11 METAL CHIP 100K 5% 1/10W
R334 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R335 1-216-837-11 METAL CHIP 22K 5% 1/10W
PANEL
Ver. 1.1
