Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC69i/EC79i/EC99i
66
R336 1-216-833-11 METAL CHIP 10K 5% 1/10W
R337 1-216-813-11 METAL CHIP 220 5% 1/10W
R362 1-216-837-11 METAL CHIP 22K 5% 1/10W
R363 1-216-837-11 METAL CHIP 22K 5% 1/10W
R369 1-216-821-11 METAL CHIP 1K 5% 1/10W
R370 1-216-821-11 METAL CHIP 1K 5% 1/10W
R376 1-216-833-11 METAL CHIP 10K 5% 1/10W
R377 1-216-833-11 METAL CHIP 10K 5% 1/10W
R378 1-216-839-11 METAL CHIP 33K 5% 1/10W
R379 1-216-843-11 METAL CHIP 68K 5% 1/10W
R380 1-216-817-11 METAL CHIP 470 5% 1/10W
R381 1-216-833-11 METAL CHIP 10K 5% 1/10W
R382 1-216-833-11 METAL CHIP 10K 5% 1/10W
R383 1-216-833-11 METAL CHIP 10K 5% 1/10W
R384 1-216-833-11 METAL CHIP 10K 5% 1/10W
R385 1-216-821-11 METAL CHIP 1K 5% 1/10W
R386 1-216-821-11 METAL CHIP 1K 5% 1/10W
R387 1-216-821-11 METAL CHIP 1K 5% 1/10W
R389 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EC69i/EC79i: UK, AUS)
R389 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC99i)
R389 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(EC79i: US, CND)
R390 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC79i/EC99i)
R391 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EC69i: UK/EC79i: UK/EC99i: UK)
R391 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EC69i: AUS/EC79i: AUS/EC99i: AUS)
R392 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC69i: US, CND, AUS/EC79i: US, CND, AUS/
EC99i: US, CND, AUS)
R396 1-216-851-11 METAL CHIP 330K 5% 1/10W
R400 1-216-821-11 METAL CHIP 1K 5% 1/10W
R401 1-216-821-11 METAL CHIP 1K 5% 1/10W
R402 1-216-845-11 METAL CHIP 100K 5% 1/10W
R412 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R413 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R414 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R415 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R416 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R417 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
(EC79i: UK, AUS/EC99i)
R418 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EC99i)
R419 1-216-838-11 METAL CHIP 27K 5% 1/10W
R420 1-216-845-11 METAL CHIP 100K 5% 1/10W
R421 1-216-833-11 METAL CHIP 10K 5% 1/10W
R422 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R433 1-216-809-11 METAL CHIP 100 5% 1/10W
R434 1-216-809-11 METAL CHIP 100 5% 1/10W
R441 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R442 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R443 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R444 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R445 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R446 1-216-846-11 METAL CHIP 120K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R447 1-216-835-11 METAL CHIP 15K 5% 1/10W
(EC79i: UK, AUS/EC99i)
R448 1-216-833-11 METAL CHIP 10K 5% 1/10W
R449 1-216-805-11 METAL CHIP 47 5% 1/10W
R450 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R452 1-216-839-11 METAL CHIP 33K 5% 1/10W
R716 1-216-821-11 METAL CHIP 1K 5% 1/10W
R717 1-249-403-11 CARBON 68 5% 1/4W
R718 1-249-403-11 CARBON 68 5% 1/4W
R719 1-249-403-11 CARBON 68 5% 1/4W
R720 1-216-837-11 METAL CHIP 22K 5% 1/10W
R722 1-216-809-11 METAL CHIP 100 5% 1/10W
< ROTARY ENCODER >
S301 1-786-417-11 ENCODER, ROTARY (VOLUME)
< SWITCH >
SW301 1-771-410-21 SWITCH, TACTILE (I/
1
) (EC79i: UK, AUS/EC99i)
SW302 1-771-410-21 SWITCH, TACTILE (DISPLAY)
(EC79i: UK, AUS/EC99i)
SW303 1-771-410-21 SWITCH, TACTILE (I/
1
) (EC69i/EC79i: US, CND)
SW313 1-771-410-21 SWITCH, TACTILE (– TUNING, l m)
SW314 1-771-410-21 SWITCH, TACTILE (u)
SW315 1-771-410-21 SWITCH, TACTILE (FOLDER –)
SW316 1-771-410-21 SWITCH, TACTILE (FUNCTION)
(EC69i/EC79i: US, CND)
SW316 1-771-410-21 SWITCH, TACTILE (EQ) (EC79i: UK, AUS/EC99i)
SW317 1-771-410-21 SWITCH, TACTILE (FUNCTION)
(EC79i: UK, AUS/EC99i)
SW318 1-771-410-21 SWITCH, TACTILE (SUBWOOFER ON/OFF)
(EC99i)
< VIBRATOR >
X301 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X302 1-813-548-31 VIBRATOR, CERAMIC (6MHz)
************************************************************
PT-SINGLE BOARD
***************
< CAPACITOR >
C001 1-165-621-91 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN002 1-820-973-11 HOLDER, CABLE 10P (EC99i)
CN003 1-819-972-11 HOLDER, CABLE 8P (EC69i/EC79i)
* CN004 1-568-226-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D001 6-500-334-01 DIODE MC2836-T112-1
D002 6-500-335-01 DIODE MC2838-T112-1
D003 6-500-335-01 DIODE MC2838-T112-1
< TRANSFORMER >
0 PT001 1-445-563-11 TRANSFORMER, POWER (EC69i: US, CND/
EC79i: US, CND/EC99i: US, CND)
0 PT002 1-443-912-11 TRANSFORMER, POWER
(EC69i: UK/EC79i: UK/EC99i: UK)
0 PT003 1-445-105-11 TRANSFORMER, POWER (EC69i: AUS/EC79i:
AUS/EC99i: AUS)
PANEL PT-SINGLE
Ver. 1.1
