Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
59
HCD-EX5
C1 1-131-714-11 ELECT 100uF 20% 400V
(AEP,UK)
C2 1-107-908-11 ELECT 33uF 20.00% 50V
C4 1-104-572-11 CERAMIC 0.0022uF 10.00% 2KV
(US,CND)
C4 1-104-569-11 CERAMIC 680PF 10.00% 2KV
(EXCEPT US,CND)
0 C6 1-131-983-11 FILM 0.1uF 10 275V
0 C7 1-131-983-11 FILM 0.1uF 10 275V
0 C8 1-131-983-11 FILM 0.1uF 10 275V
C9 1-113-907-51 CERAMIC 0.0022uF 99% 250V
C10 1-136-203-11 FILM 10000PF 5.00% 630V
0 C11 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
C12 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
0 C13 1-131-714-11 ELECT 100uF 20% 400V
(AEP,UK)
0 C13 1-131-678-11 ELECT 82uF 20% 400V
(AUS,SP,MX,HK,TW,KR)
0 C14 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
C15 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C21 1-107-905-11 ELECT 4.7uF 20.00% 50V
C22 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C24 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C25 1-164-222-91 CERAMIC CHIP 0.22uF 25V
C51 1-107-908-11 ELECT 33uF 20.00% 50V
C52 1-107-903-11 ELECT 2.2uF 20.00% 50V
C53 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C54 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C801 1-107-901-11 ELECT 0.47uF 20.00% 50V
C802 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C803 1-107-889-11 ELECT 220uF 20.00% 10V
C804 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C805 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C806 1-107-902-11 ELECT 1uF 20.00% 50V
C807 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C808 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C809 1-126-935-11 ELECT 470uF 20.00% 16V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C811 1-126-935-11 ELECT 470uF 20.00% 16V
C812 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C813 1-126-935-11 ELECT 470uF 20.00% 16V
C814 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C816 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C817 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C818 1-164-346-11 CERAMIC CHIP 1uF 16V
C821 1-136-177-00 FILM 1uF 5.00% 50V
C822 1-136-177-00 FILM 1uF 5.00% 50V
C823 1-137-194-91 FILM 0.47uF 5.00% 50V
C831 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C832 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C833 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C841 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C851 1-107-901-11 ELECT 0.47uF 20.00% 50V
C852 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C871 1-136-177-00 FILM 1uF 5.00% 50V
C872 1-136-177-00 FILM 1uF 5.00% 50V
C873 1-137-194-91 FILM 0.47uF 5.00% 50V
C881 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C882 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C883 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C891 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C899 1-135-697-11 ELECT 6800uF 16V
C901 1-104-569-11 CERAMIC 680PF 10.00% 2KV
C902 1-128-951-21 ELECT 2200uF 20% 16V
C903 1-128-951-21 ELECT 2200uF 20% 16V
C911 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C912 1-107-877-11 ELECT 1000uF 20.00% 10V
C921 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C922 1-107-877-11 ELECT 1000uF 20.00% 10V
C931 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C932 1-107-884-11 ELECT 1000uF 20.00% 16V
C951 1-164-346-11 CERAMIC CHIP 1uF 16V
C953 1-128-951-21 ELECT 2200uF 20% 16V
C954 1-104-665-11 ELECT 100uF 20.00% 10V
C955 1-164-505-11 CERAMIC CHIP 2.2uF 16V
< CONNECTOR >
* CN1 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
CN803 1-770-722-11 CONNECTOR, BOARD TO BOARD 6P
CN901 1-784-737-11 CONNECTOR, FFC 15P
< DIODE >
D1 6-500-241-01 DIODE SARS03
D2 8-719-072-11 DIODE AL01Z-WS
D3 8-719-072-11 DIODE AL01Z-WS
D4 8-719-977-28 DIODE UDZSTE-1710B
(AUS,SP,MX,HK,TW,KR)
D5 8-719-072-11 DIODE AL01Z-WS (AUS,SP,MX,HK,TW,KR)
D6 8-719-072-11 DIODE AL01Z-WS
D10 8-719-510-53 DIODE RBV-406H-01
D21 8-719-109-89 DIODE MTZJ-T-77-5.6B
D22 8-719-988-61 DIODE 1SS355TE-17
D53 8-719-084-21 DIODE 10E6N-TA1B2
D54 8-719-072-11 DIODE AL01Z-WS
D55 8-719-083-67 DIODE UDZSTE-1720B
D56 8-719-988-61 DIODE 1SS355TE-17
D57 8-719-988-61 DIODE 1SS355TE-17
D58 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-988-61 DIODE 1SS355TE-17
D821 8-719-210-21 DIODE 11EQS04-NTA1B
D822 8-719-210-21 DIODE 11EQS04-NTA1B
D823 8-719-210-21 DIODE 11EQS04-NTA1B
D824 8-719-210-21 DIODE 11EQS04-NTA1B
D871 8-719-210-21 DIODE 11EQS04-NTA1B
D872 8-719-210-21 DIODE 11EQS04-NTA1B
D873 8-719-210-21 DIODE 11EQS04-NTA1B
D874 8-719-210-21 DIODE 11EQS04-NTA1B
D901 8-719-058-38 DIODE FMN-G12S
D902 8-719-072-11 DIODE AL01Z-WS
D951 8-719-210-21 DIODE 11EQS04-NTA1B
D952 8-719-988-61 DIODE 1SS355TE-17
POWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
