Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
60
HCD-EX5
< EARTH >
* EPT1 1-537-738-21 TERMINAL, EARTH
* EPT2 1-537-738-21 TERMINAL, EARTH (US,CND)
< FUSE >
0F1 1-533-451-11 FUSE, GLASS TUBE (DIA. 5) 3.15A/125V
(US,CND)
0F1 1-533-470-11 FUSE, GLASS TUBE (DIA. 5) 3.15A/250V
(TIME-LAG) (EXCEPT US,CND)
<INDUCTOR>
FB801 1-412-473-21 INDUCTOR 0uH
< IC >
IC1 6-600-103-01 IC STR-F6254-LF1352 (US,CND)
IC1 6-600-105-01 IC STR-F6267S-LF1352 (AUS,SP,MX,HK,TW,KR)
IC1 6-600-104-01 IC STR-F6264-LF1352 (AEP,UK)
IC51 6-600-102-01 IC STR-A6459
IC101 8-759-638-11 IC TA2020-020
IC102 8-759-909-71 IC BA4558F-E2
IC911 8-759-231-53 IC M5F7805L
IC921 8-759-071-48 IC TA7807S
IC931 8-759-231-57 IC TA7810S
IC941 6-700-388-01 IC SE-B2
IC951 6-702-310-01 IC NJU7201L55-T3
< COIL >
0L1 1-456-053-11 INDUCTOR 7.7MH
0L2 1-456-053-11 INDUCTOR 7.7MH
L821 1-419-281-11 INDUCTOR 10uH
L822 1-419-281-11 INDUCTOR 10uH
L871 1-419-281-11 INDUCTOR 10uH
L872 1-419-281-11 INDUCTOR 10uH
L901 1-419-281-11 INDUCTOR 10uH
< IC >
0PC1 8-749-013-68 IC PS2561-1-D
0PC51 8-749-013-68 IC PS2561-1-D
< TRANSISTOR >
Q1 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q51 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q52 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q53 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q801 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q841 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q842 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q843 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q844 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q891 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q892 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
Q951 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q952 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q953 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6
< RESISTOR >
0 R1 1-219-237-11 SOLID 3.3M 20% 1/2W
(US,CND)
R2 1-249-417-11 CARBON 1K 5% 1/4W F
R3 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R5 1-217-153-00 METAL 0.47 10% 2W
R7 1-217-152-00 METAL 0.33 10% 2W
R8 1-249-393-11 CARBON 10 5% 1/4W F
R9 1-215-904-11 METAL OXIDE 100K 5% 2W
R21 1-249-431-11 CARBON 15K 5% 1/4W
(AUS,SP,MX,HK,TW,KR)
R22 1-216-813-11 METAL CHIP 220 5% 1/16W
R51 1-247-891-00 CARBON 330K 5% 1/4W
(EXCEPT AEP,UK)
R51 1-247-895-91 CARBON 470K 5% 1/4W
(AEP,UK)
R53 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R54 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R55 1-249-389-11 CARBON 4.7 5% 1/4W F
(EXCEPT AEP,UK)
R55 1-249-392-11 CARBON 8.2 5% 1/4W F
(AEP,UK)
R56 1-216-833-11 METAL CHIP 10K 5% 1/16W
R57 1-216-841-11 METAL CHIP 47K 5% 1/16W
R58 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R59 1-216-811-11 METAL CHIP 150 5% 1/16W
R801 1-216-833-11 METAL CHIP 10K 5% 1/16W
R802 1-216-837-11 METAL CHIP 22K 5% 1/16W
R803 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R804 1-216-857-11 METAL CHIP 1M 5% 1/16W
R805 1-216-837-11 METAL CHIP 22K 5% 1/16W
R810 1-216-809-11 METAL CHIP 100 5% 1/16W
R821 1-260-076-11 CARBON 10 5% 1/2W
R831 1-216-853-11 METAL CHIP 470K 5% 1/16W
R832 1-216-853-11 METAL CHIP 470K 5% 1/16W
R833 1-216-857-11 METAL CHIP 1M 5% 1/16W
R834 1-216-857-11 METAL CHIP 1M 5% 1/16W
R841 1-216-845-11 METAL CHIP 100K 5% 1/16W
R842 1-216-845-11 METAL CHIP 100K 5% 1/16W
R843 1-216-845-11 METAL CHIP 100K 5% 1/16W
R844 1-216-845-11 METAL CHIP 100K 5% 1/16W
R851 1-216-833-11 METAL CHIP 10K 5% 1/16W
R852 1-216-837-11 METAL CHIP 22K 5% 1/16W
R871 1-260-076-11 CARBON 10 5% 1/2W
R881 1-216-853-11 METAL CHIP 470K 5% 1/16W
R882 1-216-853-11 METAL CHIP 470K 5% 1/16W
R883 1-216-857-11 METAL CHIP 1M 5% 1/16W
R884 1-216-857-11 METAL CHIP 1M 5% 1/16W
R891 1-216-845-11 METAL CHIP 100K 5% 1/16W
R892 1-216-845-11 METAL CHIP 100K 5% 1/16W
R893 1-216-845-11 METAL CHIP 100K 5% 1/16W
R895 1-216-821-11 METAL CHIP 1K 5% 1/16W
R897 1-216-821-11 METAL CHIP 1K 5% 1/16W
R901 1-249-417-11 CARBON 1K 5% 1/4W F
R941 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R942 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R943 1-216-833-11 METAL CHIP 10K 5% 1/16W
POWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
