Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
61
HCD-EX5
R944 1-216-821-11 METAL CHIP 1K 5% 1/16W
R951 1-249-417-11 CARBON 1K 5% 1/4W F
R952 1-216-833-11 METAL CHIP 10K 5% 1/16W
R955 1-216-853-11 METAL CHIP 470K 5% 1/16W
R956 1-216-853-11 METAL CHIP 470K 5% 1/16W
R957 1-216-833-11 METAL CHIP 10K 5% 1/16W
< TRANSFORMER >
0 T1 1-437-760-11 TRANSFORMER, POWER
0 T51 1-437-761-11 TRANSFORMER, POWER
< THERMISTOR >
TH1 1-803-806-31 THERMISTOR, NTC
*************************************************************
1-684-940-11 SPK BOARD
**********
< CAPACITOR >
C824 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C825 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C826 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C874 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C875 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C876 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN801 1-537-114-11 TERMINAL BOARD (SPEAKER)
CN802 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P
< DIODE >
D892 8-719-988-61 DIODE 1SS355TE-17
< RESISTOR >
R822 1-216-797-11 METAL CHIP 10 5% 1/16W
R872 1-216-797-11 METAL CHIP 10 5% 1/16W
< RELAY >
RY891 1-755-373-11 RELAY
*************************************************************
POWER SPK
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MISCELLANEOUS
**************
52 1-773-001-11 WIRE (FLAT TYPE) (15 CORE)
109 1-693-529-11 TUNER (FM/AM) (AEP,UK)
109 1-693-531-71 TUNER (FM/AM) (AUS,SP,MX,HK,TW)
109 1-693-534-11 TUNER (FM/AM) (US,CND)
109 1-693-538-11 TUNER (FM/AM) (KR)
110 1-769-940-11 WIRE (FLAT TYPE) (11 CORE)(EXCEPT AEP,UK)
110 1-773-004-11 WIRE (FLAT TYPE) (15 CORE) (AEP,UK)
0 112 1-769-079-11 CORD, POWER (KR)
0 112 1-775-790-51 CORD, POWER (AUS)
0 112 1-777-071-62 CORD, POWER (AEP,UK,SP,HK,TW)
0 112 1-783-531-31 CORD, POWER (US,CND)
0 112 1-792-382-21 CORD, POWER (MX)
514 1-782-648-11 WIRE (FLAT TYPE)(23CORE)
M102 X-4954-294-1 MOTOR ASSY, SLED (SLED)
M701 1-763-790-11 MOTOR, DC (LO)
M702 A-4735-611-A MOTOR (CK) ASSY (CK)
Ver. 1.2
