54
HCD-GP6V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R541 1-216-857-11 METAL CHIP 1M 5% 1/10W
R542 1-216-833-11 METAL CHIP 10K 5% 1/10W
R543 1-216-837-11 METAL CHIP 22K 5% 1/10W
R544 1-249-435-11 CARBON 33K 5% 1/4W
R545 1-216-837-11 METAL CHIP 22K 5% 1/10W
R546 1-216-837-11 METAL CHIP 22K 5% 1/10W
R547 1-216-837-11 METAL CHIP 22K 5% 1/10W
R548 1-216-837-11 METAL CHIP 22K 5% 1/10W
R549 1-216-837-11 METAL CHIP 22K 5% 1/10W
R550 1-216-841-11 METAL CHIP 47K 5% 1/10W
R551 1-216-841-11 METAL CHIP 47K 5% 1/10W
R553 1-216-845-11 METAL CHIP 100K 5% 1/10W
R554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R555 1-247-878-00 CARBON 91K 5% 1/4W
R556 1-247-878-00 CARBON 91K 5% 1/4W
R570 1-216-845-11 METAL CHIP 100K 5% 1/10W
************************************************************
MIC/ECHO BOARD
***************
< CAPACITOR >
C523 1-124-252-91 ELECT 0.33uF 20% 50V
C524 not supplied
C525 1-164-230-91 CERAMIC CHIP 220PF 5% 50V
C526 1-162-915-91 CERAMIC CHIP 10PF 0.5PF 50V
C537 1-124-236-91 ELECT CHIP 47 20% 16V
C538 1-164-217-91 CERAMIC CHIP 150PF 5.00% 50V
C539 1-164-217-91 CERAMIC CHIP 150PF 5.00% 50V
C540 1-164-217-91 CERAMIC CHIP 150PF 5.00% 50V
C541 1-164-217-91 CERAMIC CHIP 150PF 5.00% 50V
C542 1-164-217-91 CERAMIC CHIP 150PF 5.00% 50V
C543 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
C545 not supplied
C546 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
C547 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
C548 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
C544 1-126-960-11 ELECT 1uF 20% 50V
C549 not supplied
C550 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C551 not supplied
C552 1-124-236-91 ELECT CHIP 47 20% 16V
C553 not supplied
C554 1-124-236-91 ELECT CHIP 47 20% 16V
C555 1-124-236-91 ELECT CHIP 47 20% 16V
C556 1-162-915-91 CERAMIC CHIP 10PF 0.5PF 50V
C557 1-162-968-81 CERAMIC CHIP 0.0047uF 10% 50V
C558 1-126-964-11 ELECT 10uF 20% 50V
C559 1-124-236-91 ELECT CHIP 47 20% 16V
C560 1-124-236-91 ELECT CHIP 47 20% 16V
C561 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C562 1-164-156-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN501 not supplied
CN502 not supplied
< DIODE >
D503 8-719-012-92 DIODE UZ-5.1BSA-TP
< IC >
IC503 6-702-788-01 IC NJM14558MD-TE2
IC504 6-702-896-01 IC BU9262AFS
< COIL >
L501 not supplied
< SHORT >
JR501 1-216-864-11 SHORT CHIP 0
JR502 1-216-864-11 SHORT CHIP 0
JR503 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q511 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q512 not supplied
< RESISTOR >
R553 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R554 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R555 1-249-406-11 CARBON 120 5% 1/4W
R556 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R557 not supplied
R558 1-216-837-11 METAL CHIP 22K 5% 1/10W
R559 1-216-809-11 METAL CHIP 100 5% 1/10W
R560 1-216-851-11 METAL CHIP 330K 5% 1/10W
R561 1-216-847-11 METAL CHIP 150K 5% 1/10W
R562 1-216-837-11 METAL CHIP 22K 5% 1/10W
R563 1-216-833-11 METAL CHIP 10K 5% 1/10W
R564 1-216-837-11 METAL CHIP 22K 5% 1/10W
R565 1-216-821-11 METAL CHIP 1K 5% 1/10W
R566 1-216-821-11 METAL CHIP 1K 5% 1/10W
R567 1-216-833-11 METAL CHIP 10K 5% 1/10W
R568 1-216-849-11 METAL CHIP 220K 5% 1/10W
R569 1-247-807-31 CARBON 100 5% 1/4W
R571 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R572 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R573 1-216-845-11 METAL CHIP 100K 5% 1/10W
R574 1-216-845-11 METAL CHIP 100K 5% 1/10W
************************************************************
PHONE BOARD
************
C201 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
C202 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D203 not supplied
D204 not supplied
D205 not supplied
D206 not supplied
< JACK >
J202 1-816-219-11 JACK, HEADPHONE (PHONES)
MIC/ECHO PHONEMAIN
