55
HCD-GP6V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< JUMPER RESISTOR >
JR201 1-216-864-91 METAL CHIP 0 5% 1/16W
< COIL >
L205 1-414-142-11 INDUCTOR 1uH
< RESISTOR >
R201 1-249-409-11 CARBON 220 5% 1/4W
R202 1-249-409-11 CARBON 220 5% 1/4W
R203 1-249-409-11 CARBON 220 5% 1/4W
R204 1-249-409-11 CARBON 220 5% 1/4W
************************************************************
POWER BOARD
*************
< CAPACITOR >
C801 1-126-941-11 ELECT 470uF 20% 25V
< CONNECTOR >
CN801 not supplied
< DIODE >
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-991-33 DIODE 1SS133T-77
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
< RESISTOR >
0 PR802 not supplied
< TRANSFORMER >
0 PT802 1-439-976-11 TRANSFORMER, POWER (SUB)
< RELAY >
0 RY801 1-755-276-11 RELAY, POWER
< SWITCH >
0 SW801 not supplied
************************************************************
A-1082-586-A VCD BOARD, COMPLETE
********************
< CAPACITOR >
C302 1-124-261-00 ELECT 10uF 20% 50V
C308 1-126-176-11 ELECT 220uF 20% 10V
C309 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C310 1-124-584-00 ELECT 100uF 20% 10V
C311 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C608 1-126-176-11 ELECT 220uF 20% 10V
C609 1-126-176-11 ELECT 220uF 20% 10V
C610 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C611 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C612 1-216-864-11 METAL CHIP 0 5% 1/16W
C703 1-164-346-11 CERAMIC CHIP 1uF 16V
C704 1-164-346-11 CERAMIC CHIP 1uF 16V
C705 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C706 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C707 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C708 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C709 1-124-584-00 ELECT 100uF 20% 10V
C710 1-124-589-11 ELECT 47uF 20% 16V
C711 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
C712 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
C713 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
C714 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
C715 1-164-346-11 CERAMIC CHIP 1uF 16V
C716 1-164-346-11 CERAMIC CHIP 1uF 16V
C717 1-164-346-11 CERAMIC CHIP 1uF 16V
C718 1-164-346-11 CERAMIC CHIP 1uF 16V
C719 1-164-346-11 CERAMIC CHIP 1uF 16V
C720 1-164-346-11 CERAMIC CHIP 1uF 16V
C721 1-164-346-11 CERAMIC CHIP 1uF 16V
C722 1-164-346-11 CERAMIC CHIP 1uF 16V
C723 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C801 1-124-589-11 ELECT 47uF 20% 16V
C802 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C803 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C804 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C806 1-124-589-11 ELECT 47uF 20% 16V
C807 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C808 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C810 1-115-156-11 CERAMIC CHIP 1uF 10V
C813 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C814 1-124-589-11 ELECT 47uF 20% 16V
C815 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C816 1-124-584-00 ELECT 100uF 20% 10V
C817 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C818 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C819 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C820 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C821 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C822 1-124-589-11 ELECT 47uF 20% 16V
C823 1-124-261-00 ELECT 10uF 20% 50V
C824 1-115-156-11 CERAMIC CHIP 1uF 10V
C825 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C826 1-124-589-11 ELECT 47uF 20% 16V
C827 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C830 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C831 1-126-961-11 ELECT 2.2uF 20.00% 50V
C834 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C835 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C836 1-124-589-11 ELECT 47uF 20% 16V
C837 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C838 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C839 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C843 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C844 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C846 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C847 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
VCDPOWERPHONE
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.2
