Sony HCD-GP7 - CD Mechanism Disassembly; THR Board, DC FAN Disassembly

11
HCD-GP7
3-5. CD Mechanism (CDM55A-K6BD47S)
3-6. THR Board, DC FAN
4
3
s crew (+BVTP 3 × 10)
1 CD plate
5 CD holder
2 w ire (flat type) 31p (CN101
)
6 CD mechanism deck
(CDM55A-K6BD47S)
CN101
3 three s crews
(+BVTT 3
× 10)
0 four s crews
(+BVTT 3
× 8)
1 three s crews
(+BVTP 3
× 10)
2 tuner(FM/AM)
6 s crew
(+BVTT 3
× 8)
qa four s crews
(+BVTP 3
× 10)
8 s crew
9 s crew
4 heat sink cove
r
qd fan bracket
qs DC fan
7 THR board
5 connector 2p
(CN992)
