Sony HCD-GP7 - Loading Board Disassembly; CD Board Disassembly

13
HCD-GP7
3-9. LOADING Board
3-10. CD Board
5 LOADING board
2 two screws (+BTP 2.6 × 6)
4 motor (LD) assy
(M901)
1 Remove the belt.
3 Remove soldering from the two points.
2 Remove soldering
from the four points.
3 wire (flat type) 16
p
5 CD board
4 wire (flat type) 21p (CN101)
1 screw(+P 2.6 × 5)
