Sony HCD-GP7 - Panel Section Diagrams

3434
HCD-GP7
7-8. Printed Wiring Board — PANEL Section — • See page 23 for Circuit Boards Location.
IC891
IC801
32
12
A
B
C
D
E
34567 8
Ref. No. Location
D802 B-4
D803 B-4
D804 B-5
D805 B-5
D806 B-5
D891 C-8
IC801 B-6
IC891 B-8
Q801 B-4
Q802 B-4
Q803 C-8
• Semiconductor
Location
• : Uses unleaded solder.
