14
HCD-GP7
3-11. Tray (CDM55D)
3-12. Optical Pick-Up (KSM-213D), Holder (C213)
2
tray
1
While pressing the two protrusions
A
and
B
to unlock the two claws as shown,
pull the tray in the direction of the arrow
C
. (Be careful of the claws.)
claw
claw
C
A
B
1
two floating
screw
(+PTPWH M2.6)
qf
floating
screws
(+PTPWH M2.6)
qg
holder
(C213)
5
screw (+PTTP M2.6)
6
stopper (BU)
2
two compression spring
(T213)
7
compression spring
(T213)
3
insulator
8
insulator
9
screw (+PTTP M2.6)
q;
stopper (BU)
qa
compression spring
(T213)
qs
insulator
qd
optical pick-up
(KSM-213DCP/C2NP)
4
insulator
