SECTION 9
ELECTRICAL PARTS LIST
52
HCD-GP7
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
A-4731-446-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C103 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C111 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C113 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-126-246-11 ELECT CHIP 220uF 20% 4V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C118 1-115-156-11 CERAMIC CHIP 1uF 10V
C119 1-115-156-11 CERAMIC CHIP 1uF 10V
C131 1-110-563-11 CERAMIC CHIP 0.068uF 10.00% 16V
C132 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C133 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C150 1-128-995-21 ELECT CHIP 100uF 20% 10V
C151 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C152 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C158 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C205 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C206 1-126-607-11 ELECT CHIP 47uF 20% 4V
C208 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C215 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C223 1-126-607-11 ELECT CHIP 47uF 20% 4V
C224 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C226 1-126-607-11 ELECT CHIP 47uF 20% 4V
C227 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C229 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C230 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C231 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C249 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C250 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C251 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C252 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C253 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C254 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C255 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C256 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C257 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C258 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C259 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C260 1-126-246-11 ELECT CHIP 220uF 20% 4V
C261 1-126-607-11 ELECT CHIP 47uF 20% 4V
C262 1-126-607-11 ELECT CHIP 47uF 20% 4V
C263 1-125-822-11 TANTAL. CHIP 10uF 20% 10V
C264 1-126-607-11 ELECT CHIP 47uF 20% 4V
C265 1-126-607-11 ELECT CHIP 47uF 20% 4V
C266 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C267 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C268 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C269 1-125-822-11 TANTAL. CHIP 10uF 20% 10V
C270 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C271 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C273 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C274 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C275 1-126-246-11 ELECT CHIP 220uF 20% 4V
C276 1-126-209-11 ELECT CHIP 100uF 20.00% 4V
C279 1-100-588-21 ELECT CHIP 1000uF 20% 6.3V
C292 1-115-156-11 CERAMIC CHIP 1uF 10V
< CONNECTOR >
CN101 1-784-387-11 CONNECTOR, FFC/FPC 31P
CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P
< FERRITE BEAD >
FB101 1-500-283-11 FERRITE 0uH
FB102 1-500-283-11 FERRITE 0uH
FB103 1-500-283-11 FERRITE 0uH
FB104 1-500-283-11 FERRITE 0uH
FB106 1-500-283-11 FERRITE 0uH
FB107 1-500-283-11 FERRITE 0uH
FB291 1-500-283-11 FERRITE 0uH
< IC >
IC101 8-752-408-73 IC CXD3068Q
