Sony HCD-GP7 - Speaker Board, Power-Amp Board Disassembly; Sub-Power Board, Power Board Disassembly

12
HCD-GP7
3-7. SPEAKER Board, POWER-AMP Board
3-8. SUB-POWER Board, POWER Board
3 SPEAKER board
8 POWER-AMP board
0 heat sin
k
qa back panel
6 amp(pwb) bracket
2 two s crews
(+BVTP 3
× 10)
1 connector 6p
(CN982)
5 s crew
(+BVTT 3
× 8)
4 s crew
(+BVTP 3
× 10)
7 two s crews
(+BVTP 3
× 16)
9 two s crews
(+BVTT 3
× 12)
3 two s crews
(+BVTT 3 × 8)
2 two s crews
(+BV SUMITITE B3)
7 four s crews
(+BV SUMITITE 4 × 8)
4 power bracket
1 connector 9p
(CN951)
T901
6 power cor
d
5 SUB-POWER board
8 POWER board
