Sony HCD-GP7 - Circuit Board Location

2323
HCD-GP7
POWER-AMP board
SUB-POWER board
THR board
SPEAKER board
POWER board
TC board
MAIN board
CD board
LOADING board
PANEL board
HP board
VOL board
CIRCUIT BOARD LOCATION
3.0 Vp-p
30.5 s
2.8 Vp-p
1 V/DIV, 40 ns/DIV
62 ns
1 V/DIV, 10 s/DIV
4 IC401 qa (XCOUT)
5 IC401 qd (XOUT)
– MAIN Board –
• Waveforms
– CD Board –
100 mV/DIV, 20 s/DIV
1 IC101 t;
(RFAC)(CD Play mode)
200 mV/DIV, 400 ns/DIV
860mVp-p
2 IC101 ra
(TE)(CD Play mode)
3 IC101 el
(FE)(CD Play mode)
100 mV/DIV, 20 s/DIV
350mVp-p
250mVp-p
12.6 Vp-p
12.3 s
6 Q642 collector
(TAPE REC mode)
5 V/DIV, 4 s/DIV
– TC Board –
17.5Vp-p
5V/DIV, 4
µ s/DIV
9.9
µ s
7 Q801 collector
– PANEL Board –
