HCD-GP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
IC103 8-752-106-21 IC CXA2647N-T4
IC104 6-704-150-01 IC CXD9717R-008
IC121 6-700-394-01 IC BA25BC0FP-E2
IC150 8-759-677-90 IC BA5947FP-E2
< COIL >
L101 1-412-063-21 INDUCTOR 68uH
< TRANSISTOR >
Q101 8-729-046-90 TRANSISTOR 2SB970-(TX).S0
< RESISTOR >
R101 1-216-864-11 METAL CHIP 0 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-845-11 METAL CHIP 100K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-847-11 METAL CHIP 150K 5% 1/10W
R113 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R114 1-216-852-11 METAL CHIP 390K 5% 1/10W
R117 1-216-846-11 METAL CHIP 120K 5% 1/10W
R118 1-216-833-11 METAL CHIP 10K 5% 1/10W
R120 1-216-846-11 METAL CHIP 120K 5% 1/10W
R122 1-216-845-11 METAL CHIP 100K 5% 1/10W
R123 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R125 1-216-836-11 METAL CHIP 18K 5% 1/10W
R126 1-216-836-11 METAL CHIP 18K 5% 1/10W
R131 1-216-843-11 METAL CHIP 68K 5% 1/10W
R132 1-216-851-11 METAL CHIP 330K 5% 1/10W
R133 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R151 1-216-833-11 METAL CHIP 10K 5% 1/10W
R152 1-216-849-11 METAL CHIP 220K 5% 1/10W
R153 1-216-864-11 METAL CHIP 0 5% 1/10W
R155 1-216-864-11 METAL CHIP 0 5% 1/10W
R156 1-216-864-11 METAL CHIP 0 5% 1/10W
R201 1-216-839-11 METAL CHIP 33K 5% 1/10W
R202 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-845-11 METAL CHIP 100K 5% 1/10W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R205 1-216-821-11 METAL CHIP 1K 5% 1/10W
R206 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R207 1-216-857-11 METAL CHIP 1M 5% 1/10W
R212 1-216-817-11 METAL CHIP 470 5% 1/10W
R213 1-216-817-11 METAL CHIP 470 5% 1/10W
R214 1-216-864-11 METAL CHIP 0 5% 1/10W
R215 1-216-864-11 METAL CHIP 0 5% 1/10W
R216 1-216-857-11 METAL CHIP 1M 5% 1/10W
R218 1-216-821-11 METAL CHIP 1K 5% 1/10W
R219 1-216-821-11 METAL CHIP 1K 5% 1/10W
R220 1-216-821-11 METAL CHIP 1K 5% 1/10W
R230 1-216-813-11 METAL CHIP 220 5% 1/10W
R231 1-216-809-11 METAL CHIP 100 5% 1/10W
R232 1-216-809-11 METAL CHIP 100 5% 1/10W
R233 1-216-809-11 METAL CHIP 100 5% 1/10W
R249 1-216-817-11 METAL CHIP 470 5% 1/10W
R250 1-216-813-11 METAL CHIP 220 5% 1/10W
R251 1-216-813-11 METAL CHIP 220 5% 1/10W
R252 1-216-857-11 METAL CHIP 1M 5% 1/10W
R253 1-216-819-11 METAL CHIP 680 5% 1/10W
R254 1-216-845-11 METAL CHIP 100K 5% 1/10W
R255 1-216-809-11 METAL CHIP 100 5% 1/10W
R257 1-216-809-11 METAL CHIP 100 5% 1/10W
R259 1-216-809-11 METAL CHIP 100 5% 1/10W
R260 1-216-821-11 METAL CHIP 1K 5% 1/10W
R265 1-216-813-11 METAL CHIP 220 5% 1/10W
R266 1-216-813-11 METAL CHIP 220 5% 1/10W
R271 1-216-833-11 METAL CHIP 10K 5% 1/10W
R272 1-216-821-11 METAL CHIP 1K 5% 1/10W
R275 1-216-833-11 METAL CHIP 10K 5% 1/10W
R276 1-216-809-11 METAL CHIP 100 5% 1/10W
R277 1-216-864-11 METAL CHIP 0 5% 1/10W
R279 1-216-809-11 METAL CHIP 100 5% 1/10W
R280 1-216-296-11 SHORT CHIP 0
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X201 1-767-408-21 VIBRATOR, CRYSTAL (16.9MHz)
************************************************************
1-689-613-11 HP BOARD
*********
< CAPACITOR >
C142 1-162-294-31 CERAMIC 0.001uF 10% 50V
C242 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CN311 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< JACK >
J321 1-816-219-11 JACK, HEADPHONE (PHONES)
************************************************************
1-674-336-12 LOADING BOARD
**************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-786-203-11 SWITCH, LEVER (SLIDE)(OPEN/CLOSE)
************************************************************
A-4747-949-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C102 1-115-871-11 ELECT 1uF 20.00% 50V
C103 1-115-871-11 ELECT 1uF 20.00% 50V
C104 1-115-871-11 ELECT 1uF 20.00% 50V
C105 1-126-795-11 ELECT 10uF 20.00% 50V
