56
HCD-GP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
PANEL
R566 1-216-833-11 METAL CHIP 10K 5% 1/10W
R567 1-216-833-11 METAL CHIP 10K 5% 1/10W
R591 1-216-809-11 METAL CHIP 100 5% 1/10W
R592 1-216-809-11 METAL CHIP 100 5% 1/10W
< THERMISTOR(POSITIVE) >
THP301 1-804-046-11 THERMISTOR, POSITIVE (RXE030)
THP302 1-216-296-11 SHORT CHIP 0
< VIBRATOR >
X401 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
X402 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
A-4747-952-A PANEL BOARD, COMPLETE
**********************
4-249-151-01 HOLDER (FL TUBE)
4-249-823-01 HOLDER, LED
< CAPACITOR >
C807 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C832 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C833 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C834 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C835 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C836 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C837 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C838 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C839 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C840 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C841 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C842 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C844 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C854 1-124-261-00 ELECT 10uF 20% 50V
C855 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C856 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C857 1-126-795-11 ELECT 10uF 20.00% 50V
C858 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C861 1-124-261-00 ELECT 10uF 20% 50V
C862 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C863 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C891 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C892 1-126-795-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CN801 1-784-739-11 CONNECTOR, FFC 17P
* CN811 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D802 8-719-991-33 DIODE 1SS133T-77
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D806 8-719-976-96 DIODE MA8047-H-TX
D891 8-719-059-98 DIODE SLR-342VCT31 ( ?/1 )
< FERRITE BEAD >
FB801 1-216-295-91 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
FL801 1-518-909-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-643-83 IC PT6315
IC891 6-600-174-01 IC RPM7240-H4 (g)
< JUMPER RESISTOR >
JR801 1-216-864-11 METAL CHIP 0 5% 1/10W
JR802 1-216-864-11 METAL CHIP 0 5% 1/10W
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q801 8-729-808-42 TRANSISTOR 2SD1624-T-TD
Q802 8-729-808-42 TRANSISTOR 2SD1624-T-TD
Q803 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R805 1-216-844-11 METAL CHIP 82K 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-809-11 METAL CHIP 100 5% 1/10W
R809 1-216-809-11 METAL CHIP 100 5% 1/10W
R810 1-216-845-11 METAL CHIP 100K 5% 1/10W
R811 1-216-845-11 METAL CHIP 100K 5% 1/10W
R830 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R853 1-216-833-11 METAL CHIP 10K 5% 1/10W
R854 1-216-809-11 METAL CHIP 100 5% 1/10W
R855 1-216-809-11 METAL CHIP 100 5% 1/10W
R861 1-216-821-11 METAL CHIP 1K 5% 1/10W
R862 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R863 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R864 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R871 1-216-821-11 METAL CHIP 1K 5% 1/10W
R872 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R881 1-216-821-11 METAL CHIP 1K 5% 1/10W
R882 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R883 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R884 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R885 1-216-833-11 METAL CHIP 10K 5% 1/10W
R891 1-216-805-11 METAL CHIP 47 5% 1/10W
R892 1-216-805-11 METAL CHIP 47 5% 1/10W
R893 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S801 1-786-050-21 SWITCH, KEY BOARD ( ?/1 )
S802 1-786-050-21 SWITCH, KEY BOARD (TUNER/BAND)
S803 1-786-050-21 SWITCH, KEY BOARD (CD u )
S804 1-786-050-21 SWITCH, KEY BOARD (TAPE b B )
S805 1-786-050-21 SWITCH, KEY BOARD (Z)
S811 1-786-050-21 SWITCH, KEY BOARD (z REC PAUSE/START)
MAIN
