HCD-GP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
S812 1-786-050-21 SWITCH, KEY BOARD (CD SYNC)
S813 1-786-050-21 SWITCH, KEY BOARD (x)
S821 1-786-050-21 SWITCH, KEY BOARD (MD)
S822 1-786-050-21 SWITCH, KEY BOARD (TUNING +)
S823 1-786-050-21 SWITCH, KEY BOARD (TUNING -)
S824 1-786-050-21 SWITCH, KEY BOARD
(PLAY MODE/TUNING MODE DIRECTION)
S825 1-786-050-21 SWITCH, KEY BOARD (REPEAT/FM MODE)
S826 1-786-050-21 SWITCH, KEY BOARD (DSG)
< TRANSFORMER >
T801 1-443-056-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
1-689-609-11 POWER BOARD
*************
< CAPACITOR >
C901 1-136-165-00 FILM 0.1uF 5.00% 50V
C902 1-136-165-00 FILM 0.1uF 5.00% 50V
C912 1-126-767-11 ELECT 1000uF 20.00% 16V
C913 1-124-584-00 ELECT 100uF 20% 10V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P
* CN902 1-764-334-11 PLUG, CONNECTOR 11P
< DIODE >
D901 8-719-028-23 DIODE D3SBA20-4101
D911 8-719-991-33 DIODE 1SS133T-77
D912 6-500-522-01 DIODE 10EDB40-TA1B2
D913 6-500-522-01 DIODE 10EDB40-TA1B2
D914 6-500-522-01 DIODE 10EDB40-TA1B2
D915 6-500-522-01 DIODE 10EDB40-TA1B2
FH901 1-533-233-31 FUSE HOLDER
FH902 1-533-233-31 FUSE HOLDER
FH903 1-533-233-31 FUSE HOLDER
FH904 1-533-233-31 FUSE HOLDER
< IC >
IC911 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q911 8-729-016-42 TRANSISTOR KTC3199GR-TP
< RESISTOR >
0R901 1-219-119-81 FUSIBLE 0.1 5% 1/4W
R911 1-249-425-11 CARBON 4.7K 5% 1/4W F
R912 1-249-441-11 CARBON 100K 5% 1/4W
R913 1-249-401-11 CARBON 47 5% 1/4W F
< RELAY >
0RY911 1-755-332-11 RELAY
< TRANSFORMER >
0T902 1-437-730-11 TRANSFORMER, POWER
************************************************************
1-689-610-11 POWER-AMP BOARD
*****************
< CAPACITOR >
C121 1-126-964-11 ELECT 10uF 20.00% 50V
C122 1-162-290-31 CERAMIC 470PF 10% 50V
C123 1-162-290-31 CERAMIC 470PF 10% 50V
C124 1-126-965-91 ELECT 22uF 20.00% 50V
C126 1-136-153-00 FILM 0.01uF 5% 50V
C127 1-136-153-00 FILM 0.01uF 5% 50V
C221 1-126-964-11 ELECT 10uF 20.00% 50V
C222 1-162-290-31 CERAMIC 470PF 10% 50V
C223 1-162-290-31 CERAMIC 470PF 10% 50V
C224 1-126-965-91 ELECT 22uF 20.00% 50V
C226 1-136-153-00 FILM 0.01uF 5% 50V
C227 1-136-153-00 FILM 0.01uF 5% 50V
C352 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C353 1-126-965-91 ELECT 22uF 20.00% 50V
C354 1-126-964-11 ELECT 10uF 20.00% 50V
C355 1-126-965-91 ELECT 22uF 20.00% 50V
C356 1-126-965-91 ELECT 22uF 20.00% 50V
C810 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< DIODE >
D321 8-719-991-33 DIODE 1SS133T-77
D322 8-719-991-33 DIODE 1SS133T-77
< TERMINAL >
EP321 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC321 6-600-089-01 IC STK403-070
< TRANSISTOR >
Q121 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q221 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q321 8-729-037-29 TRANSISTOR KRA102M-AT
Q322 8-729-037-29 TRANSISTOR KRA102M-AT
Q323 8-729-036-58 TRANSISTOR KRC102M-AT
Q324 8-729-016-42 TRANSISTOR KTC3199GR-TP
< RESISTOR >
R121 1-249-421-11 CARBON 2.2K 5% 1/4W F
R122 1-249-441-11 CARBON 100K 5% 1/4W
R123 1-249-417-11 CARBON 1K 5% 1/4W F
R124 1-249-417-11 CARBON 1K 5% 1/4W F
R125 1-249-438-11 CARBON 56K 5% 1/4W
R126 1-247-843-11 CARBON 3.3K 5% 1/4W
R127 1-249-421-11 CARBON 2.2K 5% 1/4W F
R128 1-249-438-11 CARBON 56K 5% 1/4W
0R129 1-220-755-11 METAL 0.22 10% 2W
R133 1-260-076-11 CARBON 10 5% 1/2W
R221 1-249-421-11 CARBON 2.2K 5% 1/4W F
R222 1-249-441-11 CARBON 100K 5% 1/4W
R223 1-249-417-11 CARBON 1K 5% 1/4W F
R224 1-249-417-11 CARBON 1K 5% 1/4W F
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
