HCD-GP7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R225 1-249-438-11 CARBON 56K 5% 1/4W
R226 1-247-843-11 CARBON 3.3K 5% 1/4W
R227 1-249-421-11 CARBON 2.2K 5% 1/4W F
R228 1-249-438-11 CARBON 56K 5% 1/4W
0R229 1-220-755-11 METAL 0.22 10% 2W
R233 1-260-076-11 CARBON 10 5% 1/2W
0R351 1-202-972-61 FUSIBLE 1 5% 1/4W
0R352 1-202-972-61 FUSIBLE 1 5% 1/4W
0R353 1-212-881-11 FUSIBLE 100 5% 1/4W
R359 1-249-425-11 CARBON 4.7K 5% 1/4W F
R360 1-249-429-11 CARBON 10K 5% 1/4W
R361 1-249-435-11 CARBON 33K 5% 1/4W
R373 1-249-429-11 CARBON 10K 5% 1/4W
R374 1-249-421-11 CARBON 2.2K 5% 1/4W F
R375 1-249-421-11 CARBON 2.2K 5% 1/4W F
R376 1-247-887-00 CARBON 220K 5% 1/4W
************************************************************
1-689-612-11 SPEAKER BOARD
**************
< CAPACITOR >
C128 1-164-159-21 CERAMIC 0.1uF 50V
C129 1-164-159-21 CERAMIC 0.1uF 50V
C130 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C228 1-164-159-21 CERAMIC 0.1uF 50V
C229 1-164-159-21 CERAMIC 0.1uF 50V
C230 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C371 1-126-963-11 ELECT 4.7uF 20.00% 50V
< CONNECTOR >
CN341 1-564-506-11 PLUG, CONNECTOR 3P
CN982 1-564-509-11 PLUG, CONNECTOR 6P
< DIODE >
D325 8-719-991-33 DIODE 1SS133T-77
D371 8-719-991-33 DIODE 1SS133T-77
< COIL >
L121 1-422-009-13 COIL, AIR-CORE
L221 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q371 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q372 8-729-140-04 TRANSISTOR 2SB1116-TP-LK
< RESISTOR >
R137 1-260-076-11 CARBON 10 5% 1/2W
R237 1-260-076-11 CARBON 10 5% 1/2W
R381 1-249-437-11 CARBON 47K 5% 1/4W
R382 1-249-437-11 CARBON 47K 5% 1/4W
R383 1-249-429-11 CARBON 10K 5% 1/4W
R384 1-249-441-11 CARBON 100K 5% 1/4W
R385 1-249-421-11 CARBON 2.2K 5% 1/4W F
< RELAY >
RY801 1-515-920-11 RELAY (24V)
< TERMINAL >
TM801 1-536-708-81 TERMINAL BOARD, PUSH (4P)(SPEAKER)
************************************************************
1-689-611-11 SUB-POWER BOARD
*****************
< CAPACITOR >
C141 1-109-953-11 ELECT 2.2uF 20.00% 50V
C241 1-109-953-11 ELECT 2.2uF 20.00% 50V
C358 1-126-964-11 ELECT 10uF 20.00% 50V
C359 1-104-665-11 ELECT 100uF 20.00% 10V
C360 1-126-961-11 ELECT 2.2uF 20.00% 50V
C361 1-104-665-11 ELECT 100uF 20.00% 10V
C951 1-128-550-11 ELECT 2200uF 20.00% 50V
C952 1-128-550-11 ELECT 2200uF 20.00% 50V
C953 1-136-165-00 FILM 0.1uF 5.00% 50V
C954 1-136-165-00 FILM 0.1uF 5.00% 50V
C956 1-164-159-21 CERAMIC 0.1uF 50V
C957 1-136-165-00 FILM 0.1uF 5.00% 50V
C958 1-136-165-00 FILM 0.1uF 5.00% 50V
C959 1-136-165-00 FILM 0.1uF 5.00% 50V
< CONNECTOR >
* CN322 1-564-714-11 PIN, CONNECTOR (SMALL TYPE)12P
* CN343 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN962 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P
CN972 1-564-509-11 PLUG, CONNECTOR 6P
< DIODE >
D323 8-719-991-33 DIODE 1SS133T-77
D324 8-719-991-33 DIODE 1SS133T-77
D326 8-719-991-33 DIODE 1SS133T-77
D327 8-719-991-33 DIODE 1SS133T-77
D328 8-719-991-33 DIODE 1SS133T-77
D953 6-500-522-01 DIODE 10EDB40-TA1B2
D954 6-500-522-01 DIODE 10EDB40-TA1B2
D955 6-500-522-01 DIODE 10EDB40-TA1B2
D956 6-500-522-01 DIODE 10EDB40-TA1B2
D957 6-500-522-01 DIODE 10EDB40-TA1B2
D958 6-500-522-01 DIODE 10EDB40-TA1B2
D959 6-500-522-01 DIODE 10EDB40-TA1B2
D960 6-500-522-01 DIODE 10EDB40-TA1B2
D961 8-719-991-33 DIODE 1SS133T-77
D962 8-719-991-33 DIODE 1SS133T-77
D963 6-500-522-01 DIODE 10EDB40-TA1B2
< TERMINAL >
EP951 1-537-738-21 TERMINAL, GROUND
< TRANSISTOR >
Q122 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q222 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q325 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q326 8-729-016-42 TRANSISTOR KTC3199GR-TP
Q327 8-729-016-42 TRANSISTOR KTC3199GR-TP
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
SPEAKER SUB-POWERPOWER-AMP
